Metric Conveyor Chain - M Series

Metric Conveyor Chain

Metric conveyor chains are those who are manufactured in accordance with ISO and DIN standards. We supply M-series, MC series (hollow pin), FV series, FVC series (hollow pin), and custom made to order metric conveyor chains. In addition to, we also supply a heat-treated pin option for our metric conveyor chains as well as a full lineup of metric conveyor chain sprockets. The below charts show the standard series and sizes of metric conveyor chains, for more information or to request a quote please contact us at (407) 347-3519 or email sales@usarollerchain.com and we will be happy to assist you.
Size Roller Type Pitch (P) Working Load (kN) Working Load With Heat-Treated Pins (kN) Overall Width (F) Roller Diameter Flange Thickness (G) Bushing Diameter (D5) Between Sidebars (L) Sidebar Thickness (S) Sidebar Height (H) Pin Diameter (D6)
FV40A50 A 50mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B50 B 50mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C50 C 50mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D50 D 50mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A63 A 63mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B63 B 63mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C63 C 63mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D63 D 63mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A80 A 80mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B80 B 80mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C80 C 80mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D80 D 80mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A100 A 100mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B100 B 100mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C100 C 100mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D100 D 100mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A125 A 125mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B125 B 125mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C125 C 125mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D125 D 125mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV63A63 A 63mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B63 B 63mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C63 C 63mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D63 D 63mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A80 A 80mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B80 B 80mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C80 C 80mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D80 D 80mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A100 A 100mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B100 B 100mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C100 C 100mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D100 D 100mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A125 A 125mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B125 B 125mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C125 C 125mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D125 D 125mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A160 A 160mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B160 B 160mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C160 C 160mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D160 D 160mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV90A63 A 63mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B63 B 63mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C63 C 63mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D63 D 63mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A80 A 80mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B80 B 80mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C80 C 80mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D80 D 80mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A100 A 100mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B100 B 100mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C100 C 100mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D100 D 100mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A125 A 125mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B125 B 125mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C125 C 125mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D125 D 125mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A160 A 160mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B160 B 160mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C160 C 160mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D160 D 160mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A200 A 200mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B200 B 200mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C200 C 200mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D200 D 200mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A250 A 250mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B250 B 250mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C250 C 250mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D250 D 250mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV112A100 A 100mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B100 B 100mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C100 C 100mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D100 D 100mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A125 A 125mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B125 B 125mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C125 C 125mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D125 D 125mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A160 A 160mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B160 B 160mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C160 C 160mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D160 D 160mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A200 A 200mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B200 B 200mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C200 C 200mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D200 D 200mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A250 A 250mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B250 B 250mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C250 C 250mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D250 D 250mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV140A100 A 100mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B100 B 100mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C100 C 100mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D100 D 100mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A125 A 125mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B125 B 125mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C125 C 125mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D125 D 125mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A160 A 160mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B160 B 160mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C160 C 160mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D160 D 160mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A200 A 200mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B200 B 200mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C200 C 200mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D200 D 200mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A250 A 250mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B250 B 250mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C250 C 250mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D250 D 250mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV180A125 A 125mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B125 B 125mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C125 C 125mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D125 D 125mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A160 A 160mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B160 B 160mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C160 C 160mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D160 D 160mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A200 A 200mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B200 B 200mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C200 C 200mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D200 D 200mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A250 A 250mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B250 B 250mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C250 C 250mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D250 D 250mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A315 A 315mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B315 B 315mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C315 C 315mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D315 D 315mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV250A160 A 160mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B160 B 160mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C160 C 160mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D160 D 160mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A200 A 200mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B200 B 200mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C200 C 200mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D200 D 200mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A250 A 250mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B250 B 250mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C250 C 250mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D250 D 250mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A315 A 315mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B315 B 315mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C315 C 315mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D315 D 315mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV315A160 A 160mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B160 B 160mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C160 C 160mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D160 D 160mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A200 A 200mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B200 B 200mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C200 C 200mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D200 D 200mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A250 A 250mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B250 B 250mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C250 C 250mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D250 D 250mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A315 A 315mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B315 B 315mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C315 C 315mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D315 D 315mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A400 A 400mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B400 B 400mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C400 C 400mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D400 D 400mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm

M series metric conveyor chains conform to ISO 1977 and DIN 8167 specifications and are available with four different styles of rollers (Type A, B, C, D). These chains are the most common style of metric conveyor chains out there and are used on various conveying applications around the world. We also supply M-Series sprockets and attachments for this chain.

Size
Roller Type
Pitch (P)
Working Load (kN)
Working Load With Heat-Treated Pins (kN)
Roller Diameter
Flange Thickness (G)
Pin Diameter (D6)
Overall Width (F)
Bushing Diameter (D5)
Between Sidebars (L)
Sidebar Thickness (S)
Sidebar Height (H)
M20A40 A 40mm 20 32 9mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20B40 B 40mm 20 32 12.5mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20C40 C 40mm 20 32 25mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20D40 D 40mm 20 32 32mm 3.5mm 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20A50 A 50mm 20 32 9mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20B50 B 50mm 20 32 12.5mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20C50 C 50mm 20 32 25mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20D50 D 50mm 20 32 32mm 3.5mm 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20A63 A 63mm 20 32 9mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20B63 B 63mm 20 32 12.5mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20C63 C 63mm 20 32 25mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20D63 D 63mm 20 32 32mm 3.5mm 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20A80 A 80mm 20 32 9mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20B80 B 80mm 20 32 12.5mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20C80 C 80mm 20 32 25mm -- 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M20D80 D 80mm 20 32 32mm 3.5mm 6mm 34.5mm 9mm 16mm 2.5mm 18mm
M28A50 A 50mm 28 42 10mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28B50 B 50mm 28 42 15mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28C50 C 50mm 28 42 30mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28AD50 D 50mm 28 42 36mm 4mm 7mm 38mm 10mm 18mm 3mm 20mm
M28A63 A 63mm 28 42 10mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28B63 B 63mm 28 42 15mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28C63 C 63mm 28 42 30mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28D63 D 63mm 28 42 36mm 4mm 7mm 38mm 10mm 18mm 3mm 20mm
M28A80 A 80mm 28 42 10mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28B80 B 80mm 28 42 15mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28C80 C 80mm 28 42 30mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28D80 D 80mm 28 42 36mm 4mm 7mm 38mm 10mm 18mm 3mm 20mm
M28A100 A 100mm 28 42 10mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28B100 B 100mm 28 42 15mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28C100 C 100mm 28 42 30mm -- 7mm 38mm 10mm 18mm 3mm 20mm
M28D100 D 100mm 28 42 36mm 4mm 7mm 38mm 10mm 18mm 3mm 20mm
M40A63 A 63mm 40 60 11mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40B63 B 63mm 40 60 18mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40C63 C 63mm 40 60 36mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40D63 D 63mm 40 60 45mm 4.5mm 8mm 43.25mm 11mm 20mm 4mm 25mm
M40A80 A 80mm 40 60 11mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40B80 B 80mm 40 60 18mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40C80 C 80mm 40 60 36mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40D80 D 80mm 40 60 45mm 4.5mm 8mm 43.25mm 11mm 20mm 4mm 25mm
M40A100 A 100mm 40 60 11mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40B100 B 100mm 40 60 18mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40C100 C 100mm 40 60 36mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40D100 D 100mm 40 60 45mm 4.5mm 8mm 43.25mm 11mm 20mm 4mm 25mm
M40A125 A 125mm 40 60 11mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40B125 B 125mm 40 60 18mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40C125 C 125mm 40 60 36mm -- 8mm 43.25mm 11mm 20mm 4mm 25mm
M40D125 D 125mm 40 60 45mm 4.5mm 8mm 43.25mm 11mm 20mm 4mm 25mm
M56A63 A 63mm 50 85 15mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56B63 B 63mm 50 85 21mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56C63 C 63mm 50 85 42mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56D63 D 63mm 50 85 50mm 7mm 10mm 48.5mm 15mm 24mm 4mm 30mm
M56A80 A 80mm 50 85 15mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56B80 B 80mm 50 85 21mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56C80 C 80mm 50 85 42mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56D80 D 80mm 50 85 50mm 7mm 10mm 48.5mm 15mm 24mm 4mm 30mm
M56A100 A 100mm 50 85 15mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56B100 B 100mm 50 85 21mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56C100 C 100mm 50 85 42mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56D100 D 100mm 50 85 50mm 7mm 10mm 48.5mm 15mm 24mm 4mm 30mm
M56A125 A 125mm 50 85 15mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56B125 B 125mm 50 85 21mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56C125 C 125mm 50 85 42mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56D125 D 125mm 50 85 50mm 7mm 10mm 48.5mm 15mm 24mm 4mm 30mm
M56A160 A 160mm 50 85 15mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56B160 B 160mm 50 85 21mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56C160 C 160mm 50 85 42mm -- 10mm 48.5mm 15mm 24mm 4mm 30mm
M56D160 D 160mm 50 85 50mm 7mm 10mm 48.5mm 15mm 24mm 4mm 30mm
M80A80 A 80mm 80 125 18mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80B80 B 80mm 80 125 25mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80C80 C 80mm 80 125 50mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80D80 D 80mm 80 125 60mm 7mm 12mm 58.25mm 18mm 28mm 5mm 35mm
M80A100 A 100mm 80 125 18mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80B100 B 100mm 80 125 25mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80C100 C 100mm 80 125 50mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80D100 D 100mm 80 125 60mm 7mm 12mm 58.25mm 18mm 28mm 5mm 35mm
M80A125 A 125mm 80 125 18mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80B125 B 125mm 80 125 25mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80C125 C 125mm 80 125 50mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80D125 D 125mm 80 125 60mm 7mm 12mm 58.25mm 18mm 28mm 5mm 35mm
M80A160 A 160mm 80 125 18mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80B160 B 160mm 80 125 25mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80C160 C 160mm 80 125 50mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80D160 D 160mm 80 125 60mm 7mm 12mm 58.25mm 18mm 28mm 5mm 35mm
M80A200 A 200mm 80 125 18mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80B200 B 200mm 80 125 25mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80C200 C 200mm 80 125 50mm -- 12mm 58.25mm 18mm 28mm 5mm 35mm
M80D200 D 200mm 80 125 60mm 7mm 12mm 58.25mm 18mm 28mm 5mm 35mm
M112A80 A 80mm 112 175 21mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112B80 B 80mm 112 175 30mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112C80 C 80mm 112 175 60mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112D80 D 80mm 112 175 75mm 7.5mm 15mm 67.5mm 21mm 32mm 6mm 40mm
M112A100 A 100mm 112 175 21mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112B100 B 100mm 112 175 30mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112C100 C 100mm 112 175 60mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112D100 D 100mm 112 175 75mm 7.5mm 15mm 67.5mm 21mm 32mm 6mm 40mm
M112A125 A 125mm 112 175 21mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112B125 B 125mm 112 175 30mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112C125 C 125mm 112 175 60mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112D125 D 125mm 112 175 75mm 7.5mm 15mm 67.5mm 21mm 32mm 6mm 40mm
M112A160 A 160mm 112 175 21mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112B160 B 160mm 112 175 30mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112C160 C 160mm 112 175 60mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112D160 D 160mm 112 175 75mm 7.5mm 15mm 67.5mm 21mm 32mm 6mm 40mm
M112A200 A 200mm 112 175 21mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112B200 B 200mm 112 175 30mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112C200 C 200mm 112 175 60mm -- 15mm 67.5mm 21mm 32mm 6mm 40mm
M112D200 D 200mm 112 175 75mm 7.5mm 15mm 67.5mm 21mm 32mm 6mm 40mm
M160A100 A 100mm 160 260 25mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160B100 B 100mm 160 260 36mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160C100 C 100mm 160 260 70mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160D100 D 100mm 160 260 90mm 8.5mm 18mm 77mm 25mm 37mm 7mm 50mm
M160A125 A 125mm 160 260 25mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160B125 B 125mm 160 260 36mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160C125 C 125mm 160 260 70mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160D125 D 125mm 160 260 90mm 8.5mm 18mm 77mm 25mm 37mm 7mm 50mm
M160A160 A 160mm 160 260 25mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160B160 B 160mm 160 260 36mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160C160 C 160mm 160 260 70mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160D160 D 160mm 160 260 90mm 8.5mm 18mm 77mm 25mm 37mm 7mm 50mm
M160A200 A 200mm 160 260 25mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160B200 B 200mm 160 260 36mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160C200 C 200mm 160 260 70mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160D200 D 200mm 160 260 90mm 8.5mm 18mm 77mm 25mm 37mm 7mm 50mm
M160A250 A 250mm 160 260 25mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160B250 B 250mm 160 260 36mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160C250 C 250mm 160 260 70mm -- 18mm 77mm 25mm 37mm 7mm 50mm
M160D250 D 250mm 160 260 90mm 8.5mm 18mm 77mm 25mm 37mm 7mm 50mm
M224A125 A 125mm 224 340 30mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224B125 B 125mm 224 340 42mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224C125 C 125mm 224 340 85mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224D125 D 125mm 224 340 105mm 10mm 21mm 89mm 30mm 43mm 8mm 60mm
M224A160 A 160mm 224 340 30mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224B160 B 160mm 224 340 42mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224C160 C 160mm 224 340 85mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224D160 D 160mm 224 340 105mm 10mm 21mm 89mm 30mm 43mm 8mm 60mm
M224A200 A 200mm 224 340 30mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224B200 B 200mm 224 340 42mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224C200 C 200mm 224 340 85mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224D200 D 200mm 224 340 105mm 10mm 21mm 89mm 30mm 43mm 8mm 60mm
M224A250 A 250mm 224 340 30mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224B250 B 250mm 224 340 42mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224C250 C 250mm 224 340 85mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224D250 D 250mm 224 340 105mm 10mm 21mm 89mm 30mm 43mm 8mm 60mm
M224A315 A 315mm 224 340 30mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224B315 B 315mm
224 340 42mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224C315 C 315mm 224 340 85mm -- 21mm 89mm 30mm 43mm 8mm 60mm
M224D315 D 315mm 224 340 105mm 10mm 21mm 89mm 30mm 43mm 8mm 60mm
M315A160 A 160mm 315 520 36mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315B160 B 160mm 315 520 50mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315C160 C 160mm 315 520 100mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315D160 D 160mm 315 520 124mm 10.5mm 25mm 105.5mm 36mm 48mm 10mm 70mm
M315A200 A 200mm 315 520 36mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315B200 B 200mm 315 520 50mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315C200 C 200mm 315 520 100mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315D200 D 200mm 315 520 124mm 10.5mm 25mm 105.5mm 36mm 48mm 10mm 70mm
M315A250 A 250mm 315 520 36mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315B250 B 250mm 315 520 50mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315C250 C 250mm 315 520 100mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315D250 D 250mm 315 520 124mm 10.5mm 25mm 105.5mm 36mm 48mm 10mm 70mm
M315A315 A 315mm 315 520 36mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315B315 B 315mm 315 520 50mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315C315 C 315mm 315 520 100mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315D315 D 315mm 315 520 124mm 10.5mm 25mm 105.5mm 36mm 48mm 10mm 70mm
M315A400 A 400mm 315 520 36mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315B400 B 400mm 315 520 50mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315C400 C 400mm 315 520 100mm -- 25mm 105.5mm 36mm 48mm 10mm 70mm
M315D400 D 400mm 315 520 124mm 10.5mm 25mm 105.5mm 36mm 48mm 10mm 70mm
M450A200 A 200mm 450 700 42mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450B200 B 200mm 450 700 60mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450C200 C 200mm 450 700 120mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450D200 D 200mm 450 700 149mm 11.5mm 30mm 127mm 42mm 56mm 12mm 80mm
M450A250 A 250mm 450 700 42mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450B250 B 250mm 450 700 60mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450C250 C 250mm 450 700 120mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450D250 D 250mm 450 700 149mm 11.5mm 30mm 127mm 42mm 56mm 12mm 80mm
M450A315 A 315mm 450 700 42mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450B315 B 315mm 450 700 60mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450C315 C 315mm 450 700 120mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450D315 D 315mm 450 700 149mm 11.5mm 30mm 127mm 42mm 56mm 12mm 80mm
M450A400 A 400mm 450 700 42mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450B400 B 400mm 450 700 60mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450C400 C 400mm 450 700 120mm -- 30mm 127mm 42mm 56mm 12mm 80mm
M450D400 D 400mm 450 700 149mm 11.5mm 30mm 127mm 42mm 56mm 12mm 80mm
M630A250 A 250mm 630 900 50mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630B250 B 250mm 630 900 70mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630C250 C 250mm 630 900 140mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630D250 D 250mm 630 900 170mm 15mm 36mm 143.5mm 50mm 67mm 14mm 100mm
M630A315 A 315mm 630 900 50mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630B315 B 315mm 630 900 70mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630C315 C 315mm 630 900 140mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630D315 D 315mm 630 900 170mm 15mm 36mm 143.5mm 50mm 67mm 14mm 100mm
M630A400 A 400mm 630 900 50mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630B400 B 400mm 630 900 70mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630C400 C 400mm 630 900 140mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630D400 D 400mm 630 900 170mm 15mm 36mm 143.5mm 50mm 67mm 14mm 100mm
M630A500 A 500mm 630 900 50mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630B500 B 500mm 630 900 70mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630C500 C 500mm 630 900 140mm -- 36mm 143.5mm 50mm 67mm 14mm 100mm
M630D500 D 500mm 630 900 170mm 15mm 36mm 143.5mm 50mm 67mm 14mm 100mm
M900A250 A 250mm 900 1250 60mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900B250 B 250mm 900 1250 85mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900C250 C 250mm 900 1250 170mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900D250 D 250mm 900 1250 210mm 17mm 44mm 159.5mm 60mm 78mm 16mm 120mm
M900A315 A 315mm 900 1250 60mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900B315 B 315mm 900 1250 85mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900C315 C 315mm 900 1250 170mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900D315 D 315mm 900 1250 210mm 17mm 44mm 159.5mm 60mm 78mm 16mm 120mm
M900A400 A 400mm 900 1250 60mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900B400 B 400mm 900 1250 85mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900C400 C 400mm 900 1250 170mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900D400 D 400mm 900 1250 210mm 17mm 44mm 159.5mm 60mm 78mm 16mm 120mm
M900A500 A 500mm 900 1250 60mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900B500 B 500mm 900 1250 85mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900C500 C 500mm 900 1250 170mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900D500 D 500mm 900 1250 210mm 17mm 44mm 159.5mm 60mm 78mm 16mm 120mm
M900A600 A 600mm 900 1250 60mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900B600 B 600mm 900 1250 85mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900C600 C 600mm 900 1250 170mm -- 44mm 159.5mm 60mm 78mm 16mm 120mm
M900D600 D 600mm 900 1250 210mm 17mm 44mm 159.5mm 60mm 78mm 16mm 120mm
MC Type Hollow Pin chains are manufactured in accordance to ISO and DIN dimensional specifications. These chains are made form high-strength steel and utilize a hollow pin design that makes them versatile and effective in many conveying options. More Specifically, MC chains are commonly used forpan conveyors used for cement clinker transport. For more information or to get a quote please contact us and we will be happy to assist you.
Size Pitch (P) Working Load (kN) Working Load With Heat-Treated Pins (kN) Roller Style Roller Style Flange Thickness (G) Pin Outside Diameter (D6) Hollow Pin Inside Diameter (D7) Bushing Diameter (D5) Between Sidebars (L) Sidebar Thickness (S) Sidebar Height (H) Weight (kG/ m)
MC28A50 50mm 28 40 A 17mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28B50 50mm 28 40 B 25mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28C50 50mm 28 40 C 36mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28D50 50mm 28 40 D 45mm 4.5mm 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28A63 63mm 28 40 A 17mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28B63 63mm 28 40 B 25mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28C63 63mm 28 40 C 36mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28D63 63mm 28 40 D 45mm 4.5mm 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28A80 80mm 28 40 A 17mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28B80 80mm 28 40 B 25mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28C80 80mm 28 40 C 36mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28D80 80mm 28 40 D 45mm 4.5mm 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28A100 100mm 28 40 A 17mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28B100 100mm 28 40 B 25mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28C100 100mm 28 40 C 36mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28D100 100mm 28 40 D 45mm 4.5mm 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28A125 125mm 28 40 A 17mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28B125 125mm 28 40 B 25mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28C125 125mm 28 40 C 36mm -- 13mm 8.2mm 17mm 20mm 3mm mm 25
MC28D125 125mm 28 40 D 45mm 4.5mm 13mm 8.2mm 17mm 20mm 3mm mm 25
MC56A63 63mm 56 90 A 21mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56B63 63mm 56 90 B 30mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56C63 63mm 56 90 C 50mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56D63 63mm 56 90 D 60mm 7mm 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56A80 80mm 56 90 A 21mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56B80 80mm 56 90 B 30mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56C80 80mm 56 90 C 50mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56D80 80mm 56 90 D 60mm 7mm 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56A100 100mm 56 90 A 21mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56B100 100mm 56 90 B 30mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56C100 100mm 56 90 C 50mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56D100 100mm 56 90 D 60mm 7mm 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56A125 125mm 56 90 A 21mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56B125 125mm 56 90 B 30mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56C125 125mm 56 90 C 50mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56D125 125mm 56 90 D 60mm 7mm 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56A160 160mm 56 90 A 21mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56B160 160mm 56 90 B 30mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56C160 160mm 56 90 C 50mm -- 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC56D160 160mm 56 90 D 60mm 7mm 15.5mm 10.2mm 21mm 24mm 4mm mm 35
MC112A80 80mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B80 80mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C80 80mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D80 80mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112A100 100mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B100 100mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C100 100mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D100 100mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112A125 125mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B125 125mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C125 125mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D125 125mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112A160 160mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B160 160mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C160 160mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D160 160mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112A200 200mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B200 200mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C200 200mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D200 200mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112A250 250mm 112 180 A 29mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112B250 250mm 112 180 B 42mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112C250 250mm 112 180 C 70mm -- 22mm 14.3mm 29mm 32mm 6mm mm 50
MC112D250 250mm 112 180 D 85mm 8.5mm 22mm 14.3mm 29mm 32mm 6mm mm 50
MC224A125 125mm 224 350 A 42mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224B125 125mm 224 350 B 60mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224C125 125mm 224 350 C 100mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224D125 125mm 224 350 D 120mm 10.5mm 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224A160 160mm 224 350 A 42mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224B160 160mm 224 350 B 60mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224C160 160mm 224 350 C 100mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224D160 160mm 224 350 D 120mm 10.5mm 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224A200 200mm 224 350 A 42mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224B200 200mm 224 350 B 60mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224C200 200mm 224 350 C 100mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224D200 200mm 224 350 D 120mm 10.5mm 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224A250 250mm 224 350 A 42mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224B250 250mm 224 350 B 60mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224C250 250mm 224 350 C 100mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224D250 250mm 224 350 D 120mm 10.5mm 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224A300 300mm 224 350 A 42mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224B300 300mm 224 350 B 60mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224C300 300mm 224 350 C 100mm -- 30mm 20.5mm 42mm 43mm 8mm mm 70
MC224D300 300mm 224 350 D 120mm 10.5mm 30mm 20.5mm 42mm 43mm 8mm mm 70


FV Chains are manufactured in accordance to DIN 8165 Standards and is a specific German Standard chain that is comparable to M-series metric chains. These chains are most commonly found in forestry and construction applications but are suitable for almost any conveying application. The DIN 8165 specs mean that these chains are made to very specific material and construction perimeters that ensure quality and compliance. FV chains are available with four different roller options; A type (roller-less bushed), B type (standard roller), C type (oversized roller, and D type (oversized roller with flange). We also supply sprockets and attachments for these chains.
Size Roller Type Pitch (P) Working Load (kN) Working Load With Heat-Treated Pins (kN) Overall Width (F) Roller Diameter Flange Thickness (G) Bushing Diameter (D5) Between Sidebars (L) Sidebar Thickness (S) Sidebar Height (H) Pin Diameter (D6)
FV40A50 A 50mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B50 B 50mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C50 C 50mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D50 D 50mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A63 A 63mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B63 B 63mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C63 C 63mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D63 D 63mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A80 A 80mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B80 B 80mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C80 C 80mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D80 D 80mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A100 A 100mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B100 B 100mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C100 C 100mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D100 D 100mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV40A125 A 125mm 42 47 39mm 15mm -- 15mm 18mm 3mm 25mm 10mm
FV40B125 B 125mm 42 47 39mm 20mm -- 15mm 18mm 3mm 25mm 10mm
FV40C125 C 125mm 42 47 39mm 32mm -- 15mm 18mm 3mm 25mm 10mm
FV40D125 D 125mm 42 47 39mm 50mm 4mm 15mm 18mm 3mm 25mm 10mm
FV63A63 A 63mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B63 B 63mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C63 C 63mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D63 D 63mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A80 A 80mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B80 B 80mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C80 C 80mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D80 D 80mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A100 A 100mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B100 B 100mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C100 C 100mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D100 D 100mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A125 A 125mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B125 B 125mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C125 C 125mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D125 D 125mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV63A160 A 160mm 64 75 48.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm
FV63B160 B 160mm 64 75 48.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm
FV63C160 C 160mm 64 75 48.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm
FV63D160 D 160mm 64 75 48.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm
FV90A63 A 63mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B63 B 63mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C63 C 63mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D63 D 63mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A80 A 80mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B80 B 80mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C80 C 80mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D80 D 80mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A100 A 100mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B100 B 100mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C100 C 100mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D100 D 100mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A125 A 125mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B125 B 125mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C125 C 125mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D125 D 125mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A160 A 160mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B160 B 160mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C160 C 160mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D160 D 160mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A200 A 200mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B200 B 200mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C200 C 200mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D200 D 200mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV90A250 A 250mm 100 115 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm
FV90B250 B 250mm 100 115 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm
FV90C250 C 250mm 100 115 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm
FV90D250 D 250mm 100 115 56.5mm 78mm 6.5mm 20mm 25mm 5mm 35mm 14mm
FV112A100 A 100mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B100 B 100mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C100 C 100mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D100 D 100mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A125 A 125mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B125 B 125mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C125 C 125mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D125 D 125mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A160 A 160mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B160 B 160mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C160 C 160mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D160 D 160mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A200 A 200mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B200 B 200mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C200 C 200mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D200 D 200mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV112A250 A 250mm 120 170 66mm 22mm -- 22mm 30mm 6mm 40mm 16mm
FV112B250 B 250mm 120 170 66mm 32mm -- 22mm 30mm 6mm 40mm 16mm
FV112C250 C 250mm 120 170 66mm 55mm -- 22mm 30mm 6mm 40mm 16mm
FV112D250 D 250mm 120 170 66mm 72mm 7.5mm 22mm 30mm 6mm 40mm 16mm
FV140A100 A 100mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B100 B 100mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C100 C 100mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D100 D 100mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A125 A 125mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B125 B 125mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C125 C 125mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D125 D 125mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A160 A 160mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B160 B 160mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C160 C 160mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D160 D 160mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A200 A 200mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B200 B 200mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C200 C 200mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D200 D 200mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV140A250 A 250mm 145 180 71.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm
FV140B250 B 250mm 145 180 71.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm
FV140C250 C 250mm 145 180 71.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm
FV140D250 D 250mm 145 180 71.5mm 80mm 9.5mm 26mm 35mm 6mm 45mm 18mm
FV180A125 A 125mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B125 B 125mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C125 C 125mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D125 D 125mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A160 A 160mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B160 B 160mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C160 C 160mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D160 D 160mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A200 A 200mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B200 B 200mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C200 C 200mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D200 D 200mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A250 A 250mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B250 B 250mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C250 C 250mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D250 D 250mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV180A315 A 315mm 190 250 92mm 30mm -- 30mm 45mm 8mm 50mm 20mm
FV180B315 B 315mm 190 250 92mm 42mm -- 30mm 45mm 8mm 50mm 20mm
FV180C315 C 315mm 190 250 92mm 70mm -- 30mm 45mm 8mm 50mm 20mm
FV180D315 D 315mm 190 250 92mm 125mm 13mm 30mm 45mm 8mm 50mm 20mm
FV250A160 A 160mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B160 B 160mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C160 C 160mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D160 D 160mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A200 A 200mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B200 B 200mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C200 C 200mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D200 D 200mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A250 A 250mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B250 B 250mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C250 C 250mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D250 D 250mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV250A315 A 315mm 275 300 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm
FV250B315 B 315mm 275 300 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm
FV250C315 C 315mm 275 300 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm
FV250D315 D 315mm 275 300 103.5mm 155mm 15mm 36mm 55mm 8mm 60mm 26mm
FV315A160 A 160mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B160 B 160mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C160 C 160mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D160 D 160mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A200 A 200mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B200 B 200mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C200 C 200mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D200 D 200mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A250 A 250mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B250 B 250mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C250 C 250mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D250 D 250mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A315 A 315mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B315 B 315mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C315 C 315mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D315 D 315mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm
FV315A400 A 400mm 370 480 126.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm
FV315B400 B 400mm 370 480 126.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm
FV315C400 C 400mm 370 480 126.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm
FV315D400 D 400mm 370 480 126.5mm 175mm 18mm 42mm 65mm 10mm 70mm 30mm


FVC Chains are the hollow pin equivalents to FV chains. FVC hollow pin chain can be found in forestry, construction, and pan conveyor applications. The hollow pin design makes it easy for attachment through the internal diameter of the chain bearing pin. These chains are made to DIN 8165 specs, which means that the chain is made to very specific material and construction perimeters that ensure quality and compliance. FVC chains are available with four different roller options; A type (roller-less bushed), B type (standard roller), C type (oversized roller, and D type (oversized roller with flange). We also supply sprockets and attachments for these chains.
Size Roller Type Pitch (P) Working Load (kN) Overall Width (F) Roller Diameter Flange Thickness (G) Bushing Diameter (D5) Between Sidebars (L) Sidebar Thickness (S) Sidebar Height (H) Pin Diameter (D6) Hollow Pin Inside Diameter (D7)
FVC63A63 A 63mm 46 50.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63B63 B 63mm 46 50.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63C63 C 63mm 46 50.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63D63 D 63mm 46 50.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm 8mm
FVC63A80 A 80mm 46 50.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63B80 B 80mm 46 50.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63C80 C 80mm 46 50.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63D80 D 80mm 46 50.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm 8mm
FVC63A100 A 100mm 46 50.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63B100 B 100mm 46 50.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63C100 C 100mm 46 50.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63D100 D 100mm 46 50.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm 8mm
FVC63A125 A 125mm 46 50.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63B125 B 125mm 46 50.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63C125 C 125mm 46 50.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63D125 D 125mm 46 50.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm 8mm
FVC63A160 A 160mm 46 50.5mm 18mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63B160 B 160mm 46 50.5mm 26mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63C160 C 160mm 46 50.5mm 40mm -- 18mm 22mm 4mm 30mm 12mm 8mm
FVC63D160 D 160mm 46 50.5mm 63mm 5mm 18mm 22mm 4mm 30mm 12mm 8mm
FVC90A63 A 63mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B63 B 63mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C63 C 63mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D63 D 63mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A80 A 80mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B80 B 80mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C80 C 80mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D80 D 80mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A100 A 100mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B100 B 100mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C100 C 100mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D100 D 100mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A125 A 125mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B125 B 125mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C125 C 125mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D125 D 125mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A160 A 160mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B160 B 160mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C160 C 160mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D160 D 160mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A200 A 200mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B200 B 200mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C200 C 200mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D200 D 200mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC90A250 A 250mm 73 56.5mm 20mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90B250 B 250mm 73 56.5mm 30mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90C250 C 250mm 73 56.5mm 48mm -- 20mm 25mm 5mm 35mm 14mm 10mm
FVC90D250 D 250mm 73 56.5mm 78mm 5mm 20mm 25mm 5mm 35mm 14mm 10mm
FVC112A100 A 100mm 90 63mm 22mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112B100 B 100mm 90 63mm 32mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112C100 C 100mm 90 63mm 55mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112D100 D 100mm 90 63mm 90mm 7.5mm 22mm 30mm 6mm 40mm 16mm 11mm
FVC112A125 A 125mm 90 63mm 22mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112B125 B 125mm 90 63mm 32mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112C125 C 125mm 90 63mm 55mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112D125 D 125mm 90 63mm 90mm 7.5mm 22mm 30mm 6mm 40mm 16mm 11mm
FVC112A160 A 160mm 90 63mm 22mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112B160 B 160mm 90 63mm 32mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112C160 C 160mm 90 63mm 55mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112D160 D 160mm 90 63mm 90mm 7.5mm 22mm 30mm 6mm 40mm 16mm 11mm
FVC112A200 A 200mm 90 63mm 22mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112B200 B 200mm 90 63mm 32mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112C200 C 200mm 90 63mm 55mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112D200 D 200mm 90 63mm 90mm 7.5mm 22mm 30mm 6mm 40mm 16mm 11mm
FVC112A250 A 250mm 90 63mm 22mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112B250 B 250mm 90 63mm 32mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112C250 C 250mm 90 63mm 55mm -- 22mm 30mm 6mm 40mm 16mm 11mm
FVC112D250 D 250mm 90 63mm 90mm 7.5mm 22mm 30mm 6mm 40mm 16mm 11mm
FVC140A100 A 100mm 110 68.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140B100 B 100mm 110 68.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140C100 C 100mm 110 68.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140D100 D 100mm 110 68.5mm 100mm 8.5mm 26mm 35mm 6mm 45mm 18mm 12mm
FVC140A125 A 125mm 110 68.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140B125 B 125mm 110 68.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140C125 C 125mm 110 68.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140D125 D 125mm 110 68.5mm 100mm 8.5mm 26mm 35mm 6mm 45mm 18mm 12mm
FVC140A160 A 160mm 110 68.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140B160 B 160mm 110 68.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140C160 C 160mm 110 68.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140D160 D 160mm 110 68.5mm 100mm 8.5mm 26mm 35mm 6mm 45mm 18mm 12mm
FVC140A200 A 200mm 110 68.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140B200 B 200mm 110 68.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140C200 C 200mm 110 68.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140D200 D 200mm 110 68.5mm 100mm 8.5mm 26mm 35mm 6mm 45mm 18mm 12mm
FVC140A250 A 250mm 110 68.5mm 26mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140B250 B 250mm 110 68.5mm 36mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140C250 C 250mm 110 68.5mm 60mm -- 26mm 35mm 6mm 45mm 18mm 12mm
FVC140D250 D 250mm 110 68.5mm 100mm 8.5mm 26mm 35mm 6mm 45mm 18mm 12mm
FVC180A125 A 125mm 145 88mm 30mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180B125 B 125mm 145 88mm 42mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180C125 C 125mm 145 88mm 70mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180D125 D 125mm 145 88mm 125mm 9.5mm 30mm 45mm 8mm 50mm 20mm 14mm
FVC180A160 A 160mm 145 88mm 30mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180B160 B 160mm 145 88mm 42mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180C160 C 160mm 145 88mm 70mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180D160 D 160mm 145 88mm 125mm 9.5mm 30mm 45mm 8mm 50mm 20mm 14mm
FVC180A200 A 200mm 145 88mm 30mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180B200 B 200mm 145 88mm 42mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180C200 C 200mm 145 88mm 70mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180D200 D 200mm 145 88mm 125mm 9.5mm 30mm 45mm 8mm 50mm 20mm 14mm
FVC180A250 A 250mm 145 88mm 30mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180B250 B 250mm 145 88mm 42mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180C250 C 250mm 145 88mm 70mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180D250 D 250mm 145 88mm 125mm 9.5mm 30mm 45mm 8mm 50mm 20mm 14mm
FVC180A315 A 315mm 145 88mm 30mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180B315 B 315mm 145 88mm 42mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180C315 C 315mm 145 88mm 70mm -- 30mm 45mm 8mm 50mm 20mm 14mm
FVC180D315 D 315mm 145 88mm 125mm 9.5mm 30mm 45mm 8mm 50mm 20mm 14mm
FVC250A160 A 160mm 215 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250B160 B 160mm 215 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250C160 C 160mm 215 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250D160 D 160mm 215 103.5mm 155mm 12.5mm 36mm 55mm 8mm 60mm 26mm 18mm
FVC250A200 A 200mm 215 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250B200 B 200mm 215 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250C200 C 200mm 215 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250D200 D 200mm 215 103.5mm 155mm 12.5mm 36mm 55mm 8mm 60mm 26mm 18mm
FVC250A250 A 250mm 215 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250B250 B 250mm 215 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250C250 C 250mm 215 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250D250 D 250mm 215 103.5mm 155mm 12.5mm 36mm 55mm 8mm 60mm 26mm 18mm
FVC250A315 A 315mm 295 103.5mm 36mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250B315 B 315mm 295 103.5mm 50mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250C315 C 315mm 295 103.5mm 80mm -- 36mm 55mm 8mm 60mm 26mm 18mm
FVC250D315 D 315mm 295 103.5mm 155mm 12.5mm 36mm 55mm 8mm 60mm 26mm 18mm
FVC315A160 A 160mm 295 121.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315B160 B 160mm 295 121.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315C160 C 160mm 295 121.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315D160 D 160mm 295 121.5mm 175mm 14.5mm 42mm 65mm 10mm 70mm 30mm 20mm
FVC315A200 A 200mm 295 121.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315B200 B 200mm 295 121.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315C200 C 200mm 295 121.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315D200 D 200mm 295 121.5mm 175mm 14.5mm 42mm 65mm 10mm 70mm 30mm 20mm
FVC315A250 A 250mm 295 121.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315B250 B 250mm 295 121.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315C250 C 250mm 295 121.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315D250 D 250mm 295 121.5mm 175mm 14.5mm 42mm 65mm 10mm 70mm 30mm 20mm
FVC315A315 A 315mm 295 121.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315B315 B 315mm 295 121.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315C315 C 315mm 295 121.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315D315 D 315mm 295 121.5mm 175mm 14.5mm 42mm 65mm 10mm 70mm 30mm 20mm
FVC315A400 A 400mm 295 121.5mm 42mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315B400 B 400mm 295 121.5mm 60mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315C400 C 400mm 295 121.5mm 90mm -- 42mm 65mm 10mm 70mm 30mm 20mm
FVC315D400 D 400mm 295 121.5mm 175mm 14.5mm 42mm 65mm 10mm 70mm 30mm 20mm





category-list-M Series Metric Attachments M Series Metric Attachments More Info
