FV180D160 Chain | DIN Standard FV180D160 Metric Chain Features
FV180D160 Chain | DIN Standard FV180D160 Metric Chain Specifications
FV180D160 Chain is a metric conveyor series chain that is manufactured to a very specific German DIN Standard dimensionally and material wise. More specifically FV180D160 conveyor chain is D-style flanged roller type conveyor chain used in lumber mills, water treatment, aggregate, and as a base conveyor chain in many other applications. We also supply a full range of sprockets and attachments for FV180D160 chain. Please note it is important to utilize proper lubrication to increase the working life and performance of these chains, we also offer a heat-treated pin option for more demanding applications. For additional information or to get a quote please contact us and we will be happy to assist you.
FV180D160 Chain Dimensions
- Size: FV180D160
- Roller Style: D
- Pitch (P): 160mm
- Working Load: 190kN
- Working Load With Heat Treated Pins: 250kN
- Overall Width (F): 92mm
- Roller Diameter (D3): 125mm
- Flange Diameter (D4): mm
- Flange Thickness (G): 13mm
- Bushing Diameter (D5): 30mm
- Distance Between Sidebars (L): 45mm
- Sidebar Thickness (S): 8mm
- Sidebar Height (H): 50mm
- Pin Diameter (D6): 20mm
- Size: FV180D160
- Roller Style: D
- Pitch (P): 160mm
- Working Load: 190kN
- Working Load With Heat Treated Pins: 250kN
- Overall Width (F): 92mm
- Roller Diameter (D3): 125mm
- Flange Diameter (D4): mm
- Flange Thickness (G): 13mm
- Bushing Diameter (D5): 30mm
- Distance Between Sidebars (L): 45mm
- Sidebar Thickness (S): 8mm
- Sidebar Height (H): 50mm
- Pin Diameter (D6): 20mm
