#100 Roller Chain
This #100 roller chain is manufactured in accordance with American National Standards Institute (ANSI) B29.1 standards and has been manufactured to the same dimensions since the beginning of ANSI/ ASA in 1930. Though dimensionally the exact same we offer three different quality levels of the #100 roller chain that goes above and beyond the standard strength and performance wise.Economy Plus series #100 roller chain uses heat-treated precision components and features a solid roller design for improved performance.
General Duty Plus series roller chain is essentially the same except uses a higher-heat treat thus making it better for high-speed and higher load applications.
Premier Series roller chain uses the highest-strength components that have been heat-treated, shot-peened, and hardened to a maximum. They also implement a solid bushing solid roller (SBR) design and use a premium-grade lubricant for the maximum durability, strength, and working life.
We stock a wide range of configurations for #100 roller chain including anti-corrosive, attachment chains, and specialty series.
#100 Roller Chain Dimensions
|
|
Pitch (P)
|
Roller Width (W)
|
Roller Diameter (D)
|
Overall Width (A)
|
Plate Height (H)
|
Plate Thickness (T)
|
Pin Diameter (E)
|
Weight (Per Ft)
|
|---|---|---|---|---|---|---|---|---|
| 100-1 | 1.250" | 0.750" | 0.750" | 1.698" | 1.185" | 0.158" | 0.375" | 2.80 LBS |
| 100-2 | 1.250" | 0.750" | 0.750" | 3.109" | 1.185" | 0.158" | 0.375" | 5.60 LBS |
| 100-3 | 1.250" | 0.750" | 0.750" | 4.519" | 1.185" | 0.158" | 0.375" | 8.34 LBS |
| 100-4 | 1.250" | 0.750" | 0.750" | 5.930" | 1.185" | 0.158" | 0.375" | 11.01 LBS |
| 100-5 | 1.250" | 0.750" | 0.750" | 7.340" | 1.185" | 0.158" | 0.375" | 13.81 LBS |
| 100-6 | 1.250" | 0.750" | 0.750" | 8.751" | 1.185" | 0.158" | 0.375" | 16.54 LBS |
