#200 Roller Chain
This #200 roller chain is manufactured in accordance with American National Standards Institute (ANSI) B29.1 standards and has been manufactured to the same dimensions since the beginning of ANSI/ ASA in 1930. Though dimensionally the exact same we offer three different quality levels of the #200 roller chain that goes above and beyond the standard strength and performance wise.Economy Plus series #200 roller chain uses heat-treated precision components and features a solid roller design for improved performance.
General Duty Plus series roller chain is essentially the same except uses a higher-heat treat thus making it better for high-speed and higher load applications.
Premier Series roller chain uses the highest-strength components that have been heat-treated, shot-peened, and hardened to a maximum. They also implement a solid bushing solid roller (SBR) design and use a premium-grade lubricant for the maximum durability, strength, and working life.
We stock a wide range of configurations for #200 roller chain including anti-corrosive, attachment chains, and specialty series.
#200 Roller Chain Dimensions
|
|
Pitch (P)
|
Roller Width (W)
|
Roller Diameter (D)
|
Overall Width (A)
|
Plate Height (H)
|
Plate Thickness (T)
|
Pin Diameter (E)
|
Weight (Per Ft)
|
|---|---|---|---|---|---|---|---|---|
| 200-1 | 2.500" | 1.500" | 1.563" | 3.361" | 2.368" | 0.315" | 0.782" | 11.07 LBS |
| 200-2 | 2.500" | 1.500" | 1.563" | 6.182" | 2.368" | 0.315" | 0.782" | 21.68 LBS |
| 200-3 | 2.500" | 1.500" | 1.563" | 9.003" | 2.368" | 0.315" | 0.782" | 32.42 LBS |
| 200-4 | 2.500" | 1.500" | 1.563" | 11.824" | 2.368" | 0.315" | 0.782" | 43.09 LBS |
| 200-5 | 2.500" | 1.500" | 1.563" | 14.645" | 2.368" | 0.315" | 0.782" | 53.76 LBS |
| 200-6 | 2.500" | 1.500" | 1.563" | 17.466" | 2.368" | 0.315" | 0.782" | 64.43 LBS |
