DS60A13H Sprocket (Double Single) $61.99 -
DS50P23H Sprocket (Double Single) $108.99 -
DS80ATL23H Sprocket (Double Single) $284.99 -
DS100A14 Sprocket (Double Single) $256.99 -
DS120A18 Sprocket (Double Single) $728.99 -
DS80A14H Sprocket (Double Single) $124.99 -
DS40ATB21H Sprocket (Taper Bushed) $77.99 -
DS40A16 Sprocket (Double Single) $40.99 -
DS80A21H Sprocket (Double Single) $242.99 -
DS50P24H Sprocket (Double Single) $110.99 -
DS60A17H Sprocket (Double Single) $80.99 -
DS120A17 Sprocket (Double Single) $680.99 -
DS60A20H Sprocket (Double Single) $118.99 -
DS160A18 High-Performance Sprocket 1-11/16" $1,778.99 -
DS50ATL19H Sprocket (Double Single) $96.99 -
DS140A18 Sprocket (Double Single) $915.99 -
DS60A19H Sprocket (Double Single) $101.99 -
DS20A20 Sprocket $0.00 -
DS100ATB20H Sprocket (Double Single) $456.99 -
DS100A18 Sprocket (Double Single) $372.99 -
DS140A15 Sprocket (Double Single) $728.99 -
DS80R23 Sprocket (Double Single) $296.99 -
DS60ATB18H Sprocket (Double Single) $124.99 -
DS100A15 Sprocket (Double Single) $279.99
Double Single Sprockets
Double single sprockets are designed to run two single-strand type roller chains, this is where the name "double single" came from. Typically these sprockets are A style but both BTB taper bushed and QD style is available from stock. Our double single sprockets are manufactured with hardened teeth and have a black oxide coating for superior performance and a slight corrosion resistance. Stock sizes of double single sprockets range from ANSI #40 - #160 but additional sizes can be manufactured upon request. We can also supply quick reaction custom re-bores and MTO specialty double single sprockets because of our quick reaction in-house machine shop. Something important to note is that even though these sprockets are double sprockets they will not double-strand roller chain. The charts below show the in-stock double single sprocket sizes and have clickable links to the product pages themselves.#40 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
2.650" | 1/2" | 1-1/4" | 1-13/32" | 1.2 LBS |
|
|
2.810" | 1/2" | 1-1/4" | 1-13/32" | 1.4 LBS |
|
|
2.980" | 1/2" | 1-5/16 | 1-13/32" | 1.6 LBS |
|
|
3.140" | 1/2" | 1-1/2" | 1-13/32" | 1.8 LBS |
|
|
3.300" | 5/8" | 1-11/16" | 1-13/32" | 2.2 LBS |
|
|
3.460" | 5/8" | 1-3/4" | 1-13/32" | 2.6 LBS |
|
|
3.620" | 5/8" | 1-3/4" | 1-13/32" | 2.9 LBS |
|
|
3.780" | 5/8" | 1-13/32" | 1-13/32" | 3.0 LBS |
|
|
3.940" | 5/8" | 2-1/16" | 1-13/32" | 3.5 LBS |
|
|
4.100" | 5/8" | 2-1/4" | 1-13/32" | 4.0 LBS |
|
|
4.260" | 5/8" | 2-1/4 | 1-13/32" | 4.5 LBS |
|
|
3.140" | -- | -- | 1-1/2" | 1.0 LBS |
|
|
3.300"
|
-- | -- | 1-1/2" | 1.1 LBS |
|
|
3.460" | -- | -- | 1-1/2" | 1.3 LBS |
|
|
3.620" | -- | -- | 1-1/2" | 1.3 LBS |
|
|
3.940" | -- | -- | 1-1/2" | 1.5 LBS |
|
|
4.100" | -- | -- | 1-1/2" | 1.7 LBS |
|
|
3.300" | -- | -- | 2-1/32" | 1.5 LBS |
|
|
3.620" | -- | -- | 2-1/32" | 2.0 LBS |
|
|
3.940" | -- | -- | 2-9/32" | 2.3 LBS |
|
|
4.100" | -- | -- | 2-9/32" | 2.5 LBS |
#50 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
3.320" | 5/8" | 1-1/2" | 1-21/32" | 2.1 LBS |
|
|
3.520" | 5/8" | 1-11/16" | 1-21/32" | 2.4 LBS |
|
|
3.720" | 5/8" | 1-3/4" | 1-21/32" | 2.9 LBS |
|
|
3.920" | 5/8" | 1-7/8" | 1-21/32" | 3.3 LBS |
|
|
4.120" | 5/8" | 2-1/16" | 1-21/32" | 3.7 LBS |
|
|
4.320" | 5/8" | 2-1/4" | 1-21/32" | 4.2 LBS |
|
|
4.520" | 5/8" | 2-1/4" | 1-21/32" | 4.8 LBS |
|
|
4.720" | 5/8" | 2-7/16" | 1-21/32" | 5.3 LBS |
|
|
4.920" | 5/8" | 2-5/8" | 1-21/32" | 5.8 LBS |
|
|
5.120" | 5/8" | 2-3/4" | 1-21/32" | 6.3 LBS |
|
|
3.520" | -- | -- | 1-1/2" | 1.5 LBS |
|
|
3.720" | -- | -- | 1-1/2" | 1.8 LBS |
|
|
3.920" | -- | -- | 1-1/2" | 2.2 LBS |
|
|
4.120" | -- | -- | 1-1/2" | 2.7 LBS |
|
|
4.320" | -- | -- | 1-1/2" | 5.0 LBS |
|
|
4.520" | -- | -- | 1-1/4" | 3.3 LBS |
|
|
4.920" | -- | -- | 1-1/4" | 3.7 LBS |
| 5.120" | -- | -- | 1-1/4" | 4.1 LBS | |
| 3.720" | -- | -- | 2-9/32" | 2.3 LBS | |
| 4.102" | -- | -- | 2-17/32" | 2.8 LBS | |
| 4.520" | -- | -- | 2-17/32" | 3.8 LBS | |
| 4.920" | -- | -- | 2-17/32" | 4.6 LBS | |
| 5.120" | -- | -- | 2-17/32" | 5.0 LBS |
#60 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
| 3.490" | 3/4" | 1-1/4" | 1-15/16" | 2.6 LBS | |
| 3.740" | 3/4" | 1-5/16" | 1-15/16" | 3.2 LBS | |
| 3.980" | 3/4" | 1-1/2" | 1-15/16" | 3.8 LBS | |
| 4.220" | 3/4" | 1-11/16" | 1-15/16" | 4.5 LBS | |
| 4.460" | 3/4" | 1-3/4" | 1-15/16" | 5.3 LBS | |
| 4.700" | 3/4" | 1-7/8" | 1-15/16" | 6.5 LBS | |
| 4.950" | 3/4" | 2-1/16" | 1-15/16" | 6.8 LBS | |
| 5.190" | 3/4" | 2-1/4" | 1-15/16" | 7.0 LBS | |
| 5.430" | 3/4" | 2-3/4" | 1-15/16" | 7.5 LBS | |
| 5.670" | 3/4" | 2-3/4" | 1-15/16" | 11.0 LBS | |
| 5.910" | 3/4" | 2-3/4" | 1-15/16" | 11.5 LBS | |
| 6.150" | 3/4" | 2-3/4" | 1-15/16" | 12.0 LBS | |
| 4.220" | -- | -- | 1-15/16" | 4.5 LBS | |
| 4.460" | -- | -- | 1-15/16" | 4.7 LBS | |
| 4.700" | -- | -- | 1-15/16" | 5.0 LBS | |
| 4.950" | -- | -- | 1-15/16" | 5.8 LBS | |
| 5.190" | -- | -- | 1-15/16" | 5.6 LBS | |
| 5.430" | -- | -- | 1-15/16" | 6.4 LBS | |
| 5.910" | -- | -- | 1-15/16" | 7.3 LBS | |
| 6.150" | -- | -- | 1-15/16" | 8.2 LBS | |
| 4.460" | -- | -- | -- | 4.8 LBS | |
| 4.460" | -- | -- | 1-15/16" | 3.9 LBS | |
| 4.950" | -- | -- | 1-15/16" | 5.3 LBS | |
| 5.430" | -- | -- | 1-15/16" | 5.4 LBS | |
| 5.670" | -- | -- | 2-1/2" | 6.2 LBS | |
| 5.910" | -- | -- | 2-1/2" | 6.9 LBS | |
| 6.150" | -- | -- | 2-1/2" | 7.6 LBS |
#80 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
4.660" | 1" | 2" | 2-3/16" | 6.5 LBS |
|
|
4.980" | 1" | 2-1/4" | 2-3/16" | 7.7 LBS |
|
|
5.300" | 1" | 2-3/8" | 2-3/16" | 9.1 LBS |
|
|
5.630" | 1" | 2-11/16" | 2-3/16" | 9.5 LBS |
|
|
5.950" | 1" | 2-13/16" | 2-3/16" | 10.8 LBS |
|
|
6.270" | 1" | 3-1/8" | 2-3/16" | 12.1 LBS |
|
|
6.590" | 1" | 3-1/4" | 2-3/16" | 12.8 LBS |
|
|
6.910" | 1" | 3-1/2" | 2-3/16" | 14.0 LBS |
|
|
7.240" | 1" | 3-3/4" | 2-3/16" | 16.5 LBS |
|
|
7.560" | 1" | 3-7/8" | 2-3/16" | 18.4 LBS |
|
|
7.880" | 1" | 3-7/8" | 2-3/16" | 20.5 LBS |
|
|
5.950" | -- | -- | 1-3/4" |
7.6 LBS
|
|
|
6.270" | -- | -- | 1-3/4" | 8.7 LBS |
|
|
6.590" | -- | -- | 2" | 9.7 LBS |
|
|
6.910" | -- | -- | 2" | 10.0 LBS |
|
|
7.240" | -- | -- | 2" | 12.0 LBS |
|
|
7.560" | -- | -- | 2" | 13.0 LBS |
|
|
7.880" | -- | -- | 2" | 14.5 LBS |
|
|
6.590" | -- | -- | -- | 9.9 LBS |
|
|
7.240" | -- | -- | -- | 12.3 LBS |
|
|
5.950" | -- | -- | 3-15/64" | 7.2 LBS |
|
|
6.590" | -- | -- | 3-15/64" | 10.5 LBS |
|
|
6.910" | -- | -- | 3-15/64" | 12.2 LBS |
|
|
7.240" | -- | -- | 3-23/64" | 12.8 lbs |
|
|
7.880" | -- | -- | 3-23/64" | 13.3 lbs |
#100 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
5.820" | 1" | 2-1/2" | 2-11/16" | 11.2 LBS |
|
|
6.230" | 1-1/4" | 2-3/4" | 2-11/16" | 13.5 LBS |
|
|
6.630" | 1-1/4" | 3-1/16" | 2-11/16" | 16.8 LBS |
|
|
7.030" | 1-1/4" | 3-1/4" | 2-11/16" | 19.3 LBS |
|
|
7.440" | 1-1/4" | 3-5/8" | 2-11/16" | 21.5 LBS |
|
|
7.840" | 1-1/4" | 3-3/4" | 2-11/16" | 23.0 LBS |
|
|
8.240" | 1-1/4" | 4-3/16" | 2-11/16" | 25.0 LBS |
|
|
8.640" | 1-1/4" | 4-3/16" | 2-11/16" | 26.5 LBS |
|
|
9.040" | 1-1/4" | 5-1/4" | 2-11/16" | 29.0 LBS |
|
|
6.630" | -- | -- | 1-3/4" | 12.5 LBS |
|
|
7.030" | -- | -- | 1-3/4" | 13.0 LBS |
|
|
7.440" | -- | -- | 2" | 14.0 LBS |
|
|
7.840" | -- | -- | 2" | 16.0 LBS |
|
|
8.240" | -- | -- | 2" | 20.0 LBS |
|
|
8.640" | -- | -- | 1-3/4" | 27.5 LBS |
|
|
9.040" | -- | -- | 2" | 27.5 LBS |
|
|
7.840" | -- | -- | -- | 16.2 LBS |
|
|
8.240" | -- | -- | -- | 20.5 LBS |
|
|
7.440" | -- | -- | 3-27/32" | 12.5 LBS |
|
|
8.240" | -- | -- | 3-27/32" | 18.8 LBS |
|
|
9.040" | -- | -- | 3-27/32" | 23.1 LBS |
#120 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
7.960" | 1-7/16" | 3-3/4" | 3-11/32" | 30.0 LBS |
|
|
8.440" | 1-7/16" | 4" | 3-11/32" | 34.0 LBS |
|
|
8.920" | 1-7/16" | 4-7/16" | 3-11/32" | 37.0 LBS |
|
|
9.410" | 1-7/16" | 5-3/16 | 3-11/32" | 42.0 LBS |
|
|
9.890" | 1-7/16" | 5-1/2" | 3-11/32" | 47.0 LBS |
|
|
10.370" | 1-7/16" | 5-15/16" | 3-11/32" | 51.0 LBS |
#140 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
8.720" | 1-7/16" | 3-7/8" | 3-39/64" | 35.0 LBS |
|
|
9.280" | 1-7/16" | 4-7/16" | 3-39/64" | 43.0 LBS |
|
|
9.850" | 1-7/16" | 5-1/4" | 3-39/64" | 49.0 LBS |
|
|
10.410" | 1-7/16" | 5-9/16" | 3-39/64" | 58.0 LBS |
|
|
10.980" | 1-7/16" | 6-1/8" | 3-39/64" | 66.0 LBS |
#160 Double Single Sprockets
| Sprocket Size | Outside Diameter | Stock Bore | Maximum Bore | Length Thru Bore | Sprocket Weight |
|---|---|---|---|---|---|
|
|
10.609" | 1-11/16" | 5-1/2" | 4-1/4" | 69.0 LBS |
|
|
11.255" | 1-11/16" | 6" | 4-1/4" | 75.0 LBS |
|
|
11.899" | 1-11/16" | 6-1/2" | 4-1/4" | 92.0 LBS |
|
|
12.543" | 1-11/16" | 6-13/16" | 4-1/4" | 97.0 LBS |
Needing roller chain with your double single sprockets? We have that in stock as well so not only do you save time looking, but you save on shipping costs! Below are ANSI Sizes #40 - #160 roller chains in the Economy Plus Series. These chains are manufactured with solid rollers, heat-treated components, and to ANSI B229.1 Standards. If you need something higher-quality simply click on the listing to see General Duty Plus and Premier Series listings for each size.
