NCS 720S Chain (Non Metallic)
NCS 720S Chain (Non Metallic)
Note:
Custom Cut to Length Chain Also Available
Product Code: NCS-720S-CHAIN
Shipping calculated at checkout.
Couldn't load pickup availability
Other Customers Viewed
NCS 720S Chain is a non-metallic (plastic) chain that is primarily used in rectangular clarifiers in wastewater treatment facilities. The NCS 720S non metallic chain that we have is injection molded in a way that leaves no air pockets so each link is made strong, uniform, and durable. NCS 720S chain is ideal for reducing weight throughout your system, which reduces energy consumption; increases wear life on other components, and often has a longer service life than traditional chains. We have both the F226 ant F228 attachments available for this chain right off the shelf, and if you need a complete assembly with attachments we can supply that as well with a fast assembly time. Our NCS 720S chain is manufactured to be exceptionally strong by featuring glass reinforced nylon links and acetal pins.
Besides the NCS 720S chain we also have a full line of high-quality non metallic sprockets, bearings, stub shafts, wear products, drive components, flights, and skimmers. With over 100+ years of industry knowledge USA Roller Chain and Sprockets sets its self apart from the others by provided an experienced customer support team, competitive pricing, and extensive inventory. To get pricing and availability on NCS 720S chain simply give us a call or send an email and one of our customer service representatives will be happy to get you taken care of.
Dimensions:
Besides the NCS 720S chain we also have a full line of high-quality non metallic sprockets, bearings, stub shafts, wear products, drive components, flights, and skimmers. With over 100+ years of industry knowledge USA Roller Chain and Sprockets sets its self apart from the others by provided an experienced customer support team, competitive pricing, and extensive inventory. To get pricing and availability on NCS 720S chain simply give us a call or send an email and one of our customer service representatives will be happy to get you taken care of.
- Chain Size: NCS720S
- Pitch: 6.00"
- Pin diameter (D): 0.93"
- Sidebar Height (H): 2.03"
- Barrel Diameter: 1.44"
- Maximum Sprocket Face: (A): 1.12"
- Bearing length (X): 1.81"
- Overall Width (E): 4.29"
- Head of Pin to Center Line (J): 2.10"
- End of Pin to Center Line (K): 2.19"
- Maximum Recommended Working Load: 3,100 LBS
- Average Ultimate Strength: 6,000 LBS
- Links Per 10ft: 20
- Weight: 1.5 LBS/ FT
- Link Material: Glass Reinforced Nylon
- Pin Material: Acetal
Feature
- Premium NCS 720S Chain
- Typically In-Stock
- Non-Metallic Material
- Wide Range of Attachments and Sprockets Available
- Commonly Found in Wastewater Applications
- Chain Size: NCS720S
- Pitch: 6.00"
- Pin diameter (D): 0.93"
- Sidebar Height (H): 2.03"
- Barrel Diameter: 1.44"
- Maximum Sprocket Face: (A): 1.12"
- Bearing length (X): 1.81"
- Overall Width (E): 4.29"
- Head of Pin to Center Line (J): 2.10"
- End of Pin to Center Line (K): 2.19"
- Maximum Recommended Working Load: 3,100 LBS
- Average Ultimate Strength: 6,000 LBS
- Links Per 10ft: 20
- Weight: 1.5 LBS/ FT
- Link Material: Glass Reinforced Nylon
- Pin Material: Acetal
