22X86 Round Link Chain | 86mm X 22mm Chain - Mining Chain

22X86 chain is a link chain used in mining, ash handling, cement production, and other heavy-duty applications. Link chains provide ample flexibility because of their highly versatile design and are high strength! Our 22X86 round link chain has a 86mm pitch and 22mm link bar circumference. Additionally, it is precision made from high-quality steel alloys and is built to exceed standards with superior dimensional consistency and interchangeability. We also supply a range of accessories for 22X86 round link chains like sprockets, master links, shackles, and mounting hardware. For additional information or a quote on the 22X86 link chain, contact our customer support team; we will be happy to assist you!

22X86 Chain Dimensions

• Chain Size: 22X86
• Pitch (P): 3.39"
• Dimension (D): 0.87"
• Dimension (B2): 2.91"
• Hardness: 40.00 RC
• Hardness: 375.00 BHN
• Minimum Units: 135,000 LBS
• Weight: 6.40 LBS/ FT
• Note 1: Dimensions are +/- 0.039"
• Note 2: Chain is Through-Hardened
