H-3264 Adapter Sleeve

H-3264 Adapter Sleeve

Note: Custom Cut to Length Chain Also Available
Product Code: H-3264-ADAPTER-SLEEVE
View full details
Description
Specification
This H-3264 Adapter Sleeve features a 300 millimeter (12") bore and is a premium quality, high precision adapter sleeve. H-3264 adapter sleeves are supplied with the accompanying nut, lock plate, and lock plate bolt. This adapter sleeve is made for use with 232 series spherical bearings, which we also offer a full line of. For more information or to get a quote on the adapter sleeve or spherical bearings, please contact us and we will be happy to assist you.

Dimensions:

  • Part Number: H-3264
  • Dimension (N): 300mm (12")
  • Other Bore Sizes: 11-7/16", 11-1/2", 11-15/16"
  • Dimension (H): 320mm
  • Dimension (L): 258mm
  • Dimension (D): 400mm
  • Dimension (C): 42mm
  • Dimension (W): 55mm
  • Nut Size: HM3164
  • Lock Plate Size: MS3164
  • Lock Plate Bolt: M10 X 30
  • Weight: 40 KG

Phone: (407) 347-3519
Email: sales@usarollerchain.com

Feature

  • Premium Adapter Sleeve
  • Includes Nut, Lock Plate, and Lock Plate Bolt
  • Manufactured To Strict Quality Standards
  • Typically In-Stock
Featured image
  • Part Number: H-3264
  • Dimension (N): 300mm (12")
  • Other Bore Sizes: 11-7/16", 11-1/2", 11-15/16"
  • Dimension (H): 320mm
  • Dimension (L): 258mm
  • Dimension (D): 400mm
  • Dimension (C): 42mm
  • Dimension (W): 55mm
  • Nut Size: HM3164
  • Lock Plate Size: MS3164
  • Lock Plate Bolt: M10 X 30
  • Weight: 40 KG
