WDH-580 Chain

Note: Custom Cut to Length Chain Also Available
SKU: WDH580-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock Item is unavailable

Login to Request a Quote

<p>Don’t see what you need?</p>

Don’t see what you need?

Call us

Buy it With:

 [{"variant_id":"51715467346287" , "metafield_value":""}]
WDH-580 Chain Features
WDH-580 Chain Specifications
WDH-580 chain features a large and wide pushing area, which gives it the capability of caring a sizable capacity when operating at low to even moderate speeds. WDH580 welded steel chain is found in a wide range of applications including; conveyors, forest products, grain handling, heavy duty conveyors, pulp and paper industry, sugar processing, and more! This WDH580 drag chain is engineered to be durable, reliable, and high strength. Then manufactured using a select grade of high quality heat-treated alloy steels to provide a long working life with solid performance. Additionally, this chain features heat-treated components including the pins, barrels, and side plates. Doing this makes the chain drastically stronger and makes it have a much longer working life.

WDH-580 Chain Dimensions

WDH-580 Chain
  • Chain Size: WDH580
  • Pitch (P): 8.00"
  • Ultimate Strength: 108,000 LBS
  • Sidebar Height (H): 2.00"
  • Sidebar Thickness (S): 0.50"
  • Pin Diameter (D6): 1.00"
  • Overall Width (F1): 14.63"
  • Length Of Bearing (B): 12.10"
  • Maximum Sprocket Thickness (L): 11.20"
  • Weight Per Foot: 19.40 LBS

We offer a full line of high quality WDH580 chain sprockets that exceed in quality, working life, and are supplied at remarkably great prices. We can even supply custom made to order sprockets within a really great lead-time. We can also supply WDH580 wing attachments along with the C 1/2 - C4 attachments and have them assembled onto the chain in any configuration needed. For pricing and availability on WDH-580 chain, sprockets, or attachments please contact us.

Phone: (407) 347-3519
Email: sales@usarollerchain.com
  • Chain Size: WDH580
  • Pitch (P): 8.00"
  • Ultimate Strength: 108,000 LBS
  • Sidebar Height (H): 2.00"
  • Sidebar Thickness (S): 0.50"
  • Pin Diameter (D6): 1.00"
  • Overall Width (F1): 14.63"
  • Length Of Bearing (B): 12.10"
  • Maximum Sprocket Thickness (L): 11.20"
  • Weight Per Foot: 19.40 LBS
