WD480 Chain | Welded Steel WD480 Chain

WD480 chain is a high-strength 8" pitch welded steel drag chain designed for some of the most demanding applications worldwide. Our high-quality WD480 chain is precision manufactured from premium steel alloys with high-hold welded barrels and high-strength hardened pins. The result is a WD480 chain more capable, high-strength, and durable than others. WD480 chain is designed to move bulk products from one point to another; the large barrel surface area (11" width) makes this chain highly productive. Common materials carried by the WD480 chain include; lumber, pulp, textile, ash, rock, dust, and more! At USA Roller chain, we also offer the upgraded WDH480 chains; these chains showcase improved strength and durability thanks to their fully hardened sidebars and barrels. For additional information or to get a quote on our premium WD480 or WDH480 chain, contact our customer support team, and we will be happy to assist you!

WD480 Chain Dimensions

• Chain Size: WD480
• Pitch (A): 8.00"
• Ultimate Strength: 85,000 LBS
• Sidebar Height (B): 2.00"
• Sidebar Thickness (C): 1/2"
• Pin Diameter (D): 7/8"
• Overall Width (E): 14-1/2"
• Length Of Bearing (F): 12-3/4"
• Maximum Sprocket Thickness (G): 11.00"
• Links Per Foot: 1.50"
• Weight Per Foot: 16.90 LBS

Additionally, we offer a full line of high-quality WD480 chain sprockets that exceed in quality and working life and are supplied at remarkably great prices. We can even supply custom-made to-order sprockets within a really great lead time.



We can also supply WD480 wing attachments, the C 1/2 - C4 attachments, and even the RR attachments and have them assembled onto the chain in any configuration needed.



Please get in touch with us for pricing and availability on the WD480 chain, sprockets, or attachments.
