WD120 Chain

Specialty Chain > Engineering Class Chains > Welded Steel Chain > Welded Steel Drag Chain > WD120 Drag Chain

WD120 Chain - Welded Steel Drag Chain 6" Pitch

Note: Custom Cut to Length Chain Also Available
SKU: WD120-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock Item is unavailable

Login to Request a Quote

<p>Don’t see what you need?</p>

Don’t see what you need?

Call us

Buy it With:

 [{"variant_id":"51715462955375" , "metafield_value":""}]
WD120 Chain - Welded Steel Drag Chain 6" Pitch Features
WD120 Chain - Welded Steel Drag Chain 6" Pitch Specifications
WD120 chain features a large and wide pushing area, which gives it the capability of caring a sizable capacity when operating at low to even moderate speeds. WD120 welded steel chain is found in a wide range of applications including; conveyors, forest products, grain handling, heavy duty conveyors, pulp and paper industry, sugar processing, and more! This WD120 drag chain is engineered to be durable, reliable, and high strength. Then manufactured using a select grade of high quality alloy steels to provide a long working life with solid performance.

Dimensions:
WD120 Chain
  • Chain Size: WD120
  • Pitch (A): 6.00"
  • Ultimate Strength: 85,000 LBS
  • Sidebar Height (B): 2.00"
  • Sidebar Thickness (C): 1/2"
  • Pin Diameter (D): 7/8"
  • Overall Width (E): 12.0"
  • Length Of Bearing (F): 10-1/4"
  • Maximum Sprocket Thickness (G): 8-3/4"
  • Links Per Foot: 2.0
  • Weight Per Foot: 18.0 LBS


Additionally, we offer a full line of high quality WD120 chain sprockets that exceed in quality, working life, and are supplied at remarkably great prices. We can even supply custom made to order sprockets within a really great lead-time.

WD120 Chain


We can also supply WD120 wing attachments along with the C 1/2 - C4 attachments and even the RR attachments, and have them assembled onto the chain in any configuration needed.

WD120 Chain


For pricing and availability on WD120 chain, sprockets, or attachments please contact us.

Phone: (407) 347-3519
Email: sales@usarollerchain.com
  • Chain Size: WD120
  • Pitch (A): 6.00"
  • Ultimate Strength: 85,000 LBS
  • Sidebar Height (B): 2.00"
  • Sidebar Thickness (C): 1/2"
  • Pin Diameter (D): 7/8"
  • Overall Width (E): 12.0"
  • Length Of Bearing (F): 10-1/4"
  • Maximum Sprocket Thickness (G): 8-3/4"
  • Links Per Foot: 2.0
  • Weight Per Foot: 18.0 LBS
