Premium SE15 Tensioner - Arm Style

This SE15 tensioner is manufactured using premium quality components from Italy and is designed to be extremely durable and directly interchangeable with other brands. Using an arm style tensioner increases the chain life, provides chain noise and vibrating damping, is maintenance free, has a safe operation, self adjusting, and operates at angels ranging tom -30° to + 30°. Besides the SE15 tensioner we also have a full line of roller chains, roller chain sprockets, gear boxes, electric motors, bearings, shafting, and more.

SE15 Chain Tensioner Specifications

• Tensioner Part#: PLI215
• Normal (A): 3.15"
• Hard (B): 3.94"
• Force (F1): 38.22 LBS
• Force (F2): 30.57 LBS
• Dimension (C): 4.43"
• Dimension (D): 0.41"
• Dimension (E): 1.18"
• Dimension (G): 1.18"
• Dimension (H): 0.31"
• Dimension (I): 0.20"
• Dimension (L): 2.51"
• Dimension (N): 1.97"
• Dimension (O): 0.35"
• Dimension (M): M8 X 25
• Weight: 1.06 LBS

For more information or to get pricing and availability please contact us and we will be happy to assist you.
