PII 81XHD Extra Heavy Duty (HH) Chain - 10ft Box
Note:
Custom Cut to Length Chain Also Available
SKU: PII-81XHD-Chain
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
PII 81XHD Extra Heavy Duty (HH) Chain - 10ft Box Features
PII 81XHD Extra Heavy Duty (HH) Chain - 10ft Box Specifications
PII premium 81XHD Extra Heavy Duty chain is a high-strength precision roller chain that is manufactured to specific quality specifications. 81XHD chain is the strongest and most durable 81X type chain available due to the Extra-Thick side plates on it. What really sets this 81XH roller chain apart from other brands is the fact that it features solid bushings, solid rollers, and quad staked rivets. Manufacturing a roller chain with solid bushings creates many benefits, the most important ones are; major performance gain, extended working life, more durable, and less internal friction. Adding solid rollers to the chain ensures a sturdy and consistent contact between the chain and sprocket teeth, this increase the working life of the chain because it prevents deformation of the chain and creates a better contact between the chain and sprocket. Having quad-staked rivets give the chain an added advantage in shock loaded applications and any side load the chain may experience during operation. Overall this chain really sets the bar for premium 81XHD type roller chains and is offered at an extremely competitive price. Fore more information or a large quantity quote please contact us and one of our highly trained customer service representatives will be happy to assist you.
Dimensions:
Phone: (407) 347-3519
Email: sales@usarollerchain.com
- Chain #: 81XHD
- Pitch (P): 2.609"
- Roller Width (W): 1.062"
- Roller Diameter (R): 0.905"
- Plate Height (H): 1.122"
- Plate Thickness (T): 0.312"
- Pin Diameter (D): 0.437"
- Overall Chain Width (F): 2.62"
- Overall Connecting Link Width: 2.75"
- Tensile Strength: 43,000 LBS
- Weight Per Foot: 4.5 LBS
Email:
- Chain #: 81XHD
- Pitch (P): 2.609"
- Roller Width (W): 1.062"
- Roller Diameter (R): 0.905"
- Plate Height (H): 1.122"
- Plate Thickness (T): 0.312"
- Pin Diameter (D): 0.437"
- Overall Chain Width (F): 1.875"
- Overall Connecting Link Width: 2.250"
- Tensile Strength: 43,000 LBS
- Weight Per Foot: 4.5 LBS
