Power Transmission > High-Quality V-Belts > Classic V-Belts
A48 V-Belt - 50" A-Section A48 Belt (4L500 Belt)
Note:
Custom Cut to Length Chain Also Available
SKU: A48-V-BELT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
Buy it With:
A48 V-Belt - 50" A-Section A48 Belt (4L500 Belt) Features
A48 V-Belt - 50" A-Section A48 Belt (4L500 Belt) Specifications
Add a high-quality part at a low price to your machinery with a 4L500 belt from USA Roller Chain. Every length has a combination of natural and styrene-butadiene rubber as the compound, high-strength polyester on the cord and high-quality cotton-poly blend for the cover. When it comes to an A48 belt that can withstand the harshest environments, USA Roller Chain's inventory wins out every time.
Check out the specifications on this 4L500 V-belt, including its 0.41-inch thickness, 0.66-inch top width and 50-inch outside length. The applications are practically endless for this classic V-belt, such as using it as a replacement belt for Husky air compressor products. Use the A48 V-belt in tandem applications as well. In fact, stocking up on these items can ward off downtime when machines break down. It won't be the V-belt holding you back anymore.
A48 V-Belt Construction:
- Cover - High-quality cotton/ polyester blend
- Compound - Natural rubber/ styrene-butadiene rubber (SBR)
- Cord - High-strength polyester
A48 V-Belt Dimensions
Belt Size: A48
- Top Width: 0.66"
- Thickness: 0.41"
- Angel: 40 Degrees
- Outside Length: 50"
- Weight: 0.30 LBS
- Interchanges: A-48, 4L500
A48 V-Belt Pulleys
Our A-section v-belt pulleys are made to ARPM standards, are extreme performance parts, and boast premium features at budget-friendly prices. The charts below show the standard pulley sizes, for additional or custom options, please contact us and we will be happy to assist you.AK V-Belt Pulleys:
| Size | Outside Diameter | Pitch Diameter (4L/A) | Pitch Diameter (3L) | Type | Dimension (F) | Dimension (L) | Dimension (P) | Dimension (C) | Pulley Weight |
|---|---|---|---|---|---|---|---|---|---|
| AK17 | 1.75" | 1.50" | 1.16" | 1 | 21/32" | 15/16" | 7/16" | 5/32" | 0.2 LBS |
| AK20 | 2.00" | 1.80" | 1.46" | 1 | 21/32" | 15/16" | 7/16" | 5/32" | 0.3 LBS |
| AK21 | 2.10" | 1.90" | 1.56" | 1 | 21/32" | 15/16" | 7/16" | 5/32" | 0.4 LBS |
| AK22 | 2.20" | 2.00" | 1.66" | 1 | 21/32" | 15/16" | 7/16" | 5/32" | 0.5 LBS |
| AK23 | 2.30" | 2.10" | 1.76" | 1 | 21/32" | 15/16" | 7/16" | 5/32" | 0.5 LBS |
| AK25 | 2.50" | 2.30" | 1.96" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.5 LBS |
| AK26 | 2.60" | 2.40" | 2.06" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.5 LBS |
| AK27 | 2.70" | 2.50" | 2.16" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.6 LBS |
| AK28 | 2.80" | 2.60" | 2.26" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.7 LBS |
| AK30 | 3.05" | 2.80" | 2.46" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.7 LBS |
| AK32 | 3.25" | 3.00" | 2.66" | 2 | 21/32" | 15/16" | 7/16" | 5/32" | 0.7 LBS |
| AK34 | 3.45" | 3.20" | 2.86" | 2 | 21/32" | 15/16" | 7/16" | 5/32" |
0.9 LBS |
| AK39 | 3.75" | 3.50" | 3.16" | 2 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.4 LBS |
| AK41 | 3.95" | 3.70" | 3.36" | 2 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.5 LBS |
| AK44 | 4.25" | 4.00" | 3.66" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.5 LBS |
| AK46 | 4.45" | 4.20" | 3.86" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.5 LBS |
| AK49 | 4.75" | 4.50" | 4.16" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.7 LBS |
| AK51 | 4.95" | 4.70" | 4.36" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.7 LBS |
| AK54 | 5.25" | 5.00" | 4.66" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.8 LBS |
| AK56 | 5.45" | 5.20" | 4.86" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 1.9 LBS |
| AK59 | 5.75" | 5.50" | 5.16" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 2.0 LBS |
| AK61 | 5.95" | 5.70" | 5.36" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 2.1 LBS |
| AK64 | 6.25" | 6.00" | 5.66" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 2.2 LBS |
| AK66 | 6.45" | 6.20" | 5.86" | 3 | 3/4" | 1-5/32" | 15/32" | 1/16" | 2.3 LBS |
| AK69 | 6.75" | 6.50" | 6.16" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 3.5 LBS |
| AK71 | 6.95" | 6.70" | 6.36" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 3.8 LBS |
| AK74 | 7.25" | 7.00" | 6.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 3.4 LBS |
| AK79 | 7.75" | 7.50" | 7.16" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 4.0 LBS |
| AK84 | 8.25" | 8.00" | 7.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 3.8 LBS |
| AK89 | 8.75" | 8.50" | 8.16" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 4.3 LBS |
| AK94 | 9.25" | 9.00" | 8.68" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 4.5 LBS |
| AK99 | 9.75" | 9.50" | 9.16" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 5.3 LBS |
| AK104 | 10.25" | 10.00" | 9.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 5.1 LBS |
| AK109 | 10.75" | 10.50" | 10.16" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 5.8 LBS |
| AK114 | 11.25" | 11.00" | 10.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 5.6 LBS |
| AK124 | 12.25" | 12.00" | 11.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 6.5 LBS |
| AK134 | 13.25" | 13.00" | 12.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 7.5 LBS |
| AK144 | 14.25" | 14.00" | 13.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 8.5 LBS |
| AK154 | 15.25" | 15.00" | 14.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- | 9.8 LBS |
| AK184 | 18.25" | 18.00" | 17.66" | 3 | 3/4" | 1-15/32" | 23/32" | -- |
12.1 LBS |
| Size | Outside Diameter | Pitch Diameter (4L/A) | Pitch Diameter (3L) | Type | Dimension (F) | Dimension (L) | Dimension (P) | Dimension (C) | Pulley Weight |
|---|---|---|---|---|---|---|---|---|---|
| 2AK20 | 2.00" | 1.80" | 1.46" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 0.8 LBS |
| 2AK21 | 2.15" | 1.90" | 1.56" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 0.9 LBS |
| 2AK22 | 2.25" | 2.00" | 1.66" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 0.9 LBS |
| 2AK23 | 2.35" | 2.10" | 1.76" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.1 LBS |
| 2AK25 | 2.55" | 2.30" | 1.96" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.3 LBS |
| 2AK26 | 2.65" | 2.40" | 2.06" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.4 LBS |
| 2AK27 | 2.75" | 2.50" | 2.16" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.5 LBS |
| 2AK28 | 2.85" | 2.60" | 2.26" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.8 LBS |
| 2AK30 | 3.05" | 2.80" | 2.46" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 1.8 LBS |
| 2AK32 | 3.25" | 3.00" | 2.66" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 2.1 LBS |
| 2AK34 | 3.45" | 3.20" | 2.86" | 1 | 1-3/8" | 1-21/32" | 15/32" | 3/16" | 2.3 LBS |
| 2AK39 | 3.75" | 3.50" | 3.16" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 2.6 LBS |
| 2AK41 | 3.95" | 3.70" | 3.36" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 2.9 LBS |
| 2AK44 | 4.25" | 4.00" | 3.66" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.0 LBS |
| 2AK46 | 4.45" | 4.20" | 3.86" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.1 LBS |
| 2AK49 | 4.75" | 4.50" | 4.16" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.6 LBS |
| 2AK51 | 4.95" | 4.70" | 4.36" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.8 LBS |
| 2AK54 | 5.25" | 5.00" | 4.66" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.3 LBS |
| 2AK56 | 5.45" | 5.20" | 4.86" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.4 LBS |
| 2AK59 | 5.75 " | 5.50" | 5.16" | 2 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.5 LBS |
| 2AK61 | 5.95" | 5.70" | 5.36" | 3 | 1-3/8" | 1-11/32" | 15/32" | 1/2" | 3.6 LBS |
| 2AK64 | 6.25" | 6.00" | 5.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 4.8 LBS |
| 2AK74 | 7.25" | 7.00" | 6.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 5.6 LBS |
| 2AK84 | 8.25" | 8.00" | 7.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 6.4 LBS |
| 2AK94 | 9.25" | 9.00" | 8.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 7.3 LBS |
| 2AK104 | 10.25" | 10.00" | 9.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 8.1 LBS |
| 2AK114 | 11.25" | 11.00" | 10.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 9.0 LBS |
| 2AK124 | 12.25" | 12.00" | 11.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 9.8 LBS |
| 2AK134 | 13.25" | 13.00" | 12.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 12.3 LBS |
| 2AK144 | 14.25" | 14.00" | 13.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 13.9 LBS |
| 2AK154 | 15.25" | 15.00" | 14.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" | 14.3 LBS |
| 2AK184 | 18.25" | 18.00" | 17.66" | 3 | 1-3/8" | 1-19/32" | 11/32" | 1/8" |
17.4 LBS |
| Size | Outside Diameter | Pitch Diameter (4L/A) | Pitch Diameter (3L) | Type | Dimension (O.L.) | Dimension (F) | Dimension (L) | Dimension (P) | Dimension (C) | Dimension (X) | Dimension (G) | Dimension (E) | Pulley Weight (LBS) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AK30H | 3.05" | 2.80" | 2.46" | 1 | 1-13/16" | 3/4" | 1-1/4" | 7/8" | -- | 1-3/16" | 7/16" | 3/16" | 0.2 |
| AK32H | 3.25" | 3.00" | 2.66" | 1 | 1-13/16" | 3/4" | 1-1/4" | 7/8" | -- | 1-3/16" | 7/16" | 3/16" | 0.3 |
| AK34H | 3.45" | 3.20" | 2.86" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.4 |
| AK39H | 3.75" | 3.50" | 3.16" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.5 |
| AK41H | 3.95" | 3.70" | 3.36" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.5 |
| AK44H | 4.25" | 4.00" | 3.66" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.5 |
| AK46H | 4.45" | 4.20" | 3.86" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.5 |
| AK49H | 4.75" | 4.50" | 4.16" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.6 |
| AK51H | 4.95" | 4.70" | 4.36" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.7 |
| AK54H | 5.25" | 5.00" | 4.66" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.7 |
| AK56H | 5.45" | 5.20" | 4.86" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.7 |
| AK59H | 5.75" | 5.50" | 5.16" | 2 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | -- | 7/8" | 7/16" | 3/16" | 0.9 |
| AK61H | 5.95" | 5.70" | 5.36" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.4 |
| AK64H | 6.25" | 6.00" | 5.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.5 |
| AK66H | 6.45" | 6.20" | 5.86" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.5 |
| AK69H | 6.75" | 6.50" | 6.16" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.5 |
| AK71H | 6.95" | 6.70" | 6.36" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.7 |
| AK74H | 7.25" | 7.00" | 6.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.7 |
| AK79H | 7.75" | 7.50" | 7.16" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.8 |
| AK84H | 8.25" | 8.00" | 7.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 1.9 |
| AK89H | 8.75" | 8.50" | 8.16" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 2.0 |
| AK94H | 9.25" | 9.00" | 8.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 2.1 |
| AK99H | 9.75" | 9.50" | 9.16" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 2.2 |
| AK104H | 10.25" | 10.00" | 9.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 2.3 |
| AK109H | 10.75" | 10.50" | 10.16" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 3.5 |
| AK114H | 11.25" | 11.00" | 10.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 3.8 |
| AK124H | 12.25" | 12.00" | 11.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 3.4 |
| AK134H | 13.25" | 13.00" | 12.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 4.0 |
| AK144H | 14.25" | 14.00" | 13.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 3.8 |
| AK154H | 15.25" | 15.00" | 14.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" | 4.3 |
| AK184H | 18.25" | 18.00" | 17.66" | 3 | 1-1/2" | 3/4" | 1-1/4" | 9/16" | 0" | 7/8" | 7/16" | 3/16" |
4.5 |
| Size | Outside Diameter | Pitch Diameter (4L/A) | Pitch Diameter (3L) | Type | Dimension (O.L.) | Dimension (F) | Dimension (L) | Dimension (P) | Dimension (C) | Dimension (X) | Dimension (G) | Dimension (E) | Pulley Weight (LBS) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2AK30H | 3.05" | 2.80" | 2.46" | 1 | 2-7/16" | 1-3/8" | 1-1/4" | 7/8" | 15/16" | 7/8" | 7/16" | 3/16" | 1.4 |
| 2AK32H | 3.25" | 3.00" | 2.66" | 1 | 2-7/16" | 1-3/8" | 1-1/4" | 7/8" | 15/16" | 7/8" | 7/16" | 3/16" | 1.7 |
| 2AK34H | 3.45" | 3.20" | 2.86" | 1 | 2" | 1-3/8" | 1-1/4" | 7/16" | 1/2" | 7/8" | 7/16" | 3/16" | 1.8 |
| 2AK39H | 3.75" | 3.50" | 3.16" | 1 | 2" | 1-3/8" | 1-1/4" | 7/16" | 1/2" | 7/8" | 7/16" | 3/16" | 1.8 |
| 2AK41H | 3.95" | 3.70" | 3.36" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 1.9 |
| 2AK44H | 4.25" | 4.00" | 3.66" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 2.4 |
| 2AK46H | 4.45" | 4.20" | 3.86" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 2.5 |
| 2AK49H | 4.75" | 4.50" | 4.16" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 3.1 |
| 2AK51H | 4.95" | 4.70" | 4.36" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 3.2 |
| 2AK54H | 5.25" | 5.00" | 4.66" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 3.4 |
| 2AK56H | 5.45" | 5.20" | 4.86" | 2 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | -- | 7/8" | 7/16" | 3/16" | 3.6 |
| 2AK59H | 5.75" | 5.50" | 5.16" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 3.4 |
| 2AK61H | 5.95" | 5.70" | 5.36" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 3.3 |
| 2AK64H | 6.25" | 6.00" | 5.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 3.9 |
| 2AK74H | 7.25" | 7.00" | 6.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 4.9 |
| 2AK84H | 8.25" | 8.00" | 7.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 5.8 |
| 2AK94H | 9.25" | 9.00" | 8.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 6.1 |
| 2AK104H | 10.25" | 10.00" | 9.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 7.7 |
| 2AK114H | 11.25" | 11.00" | 10.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 8.5 |
| 2AK124H | 12.25" | 12.00" | 11.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 9.5 |
| 2AK134H | 13.25" | 13.00" | 12.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 11.9 |
| 2AK144H | 14.25" | 14.00" | 13.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 11.9 |
| 2AK154H | 15.25" | 15.00" | 14.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 13.3 |
| 2AK184H | 18.25" | 18.00" | 17.66" | 3 | 1-1/2" | 1-3/8" | 1-1/4" | 1/16" | 0" | 7/8" | 7/16" | 3/16" | 16.8 |
- Belt Size: A48
- Top Width: 0.66"
- Thickness: 0.41"
- Angel: 40 Degrees
- Outside Length: 50"
- Weight: 0.30 LBS
- Interchanges: A-48, 4L500
