D35B12 Sprocket With Stock Bore
Note:
Custom Cut to Length Chain Also Available
$16.99
SKU: D35B12-SPROCKET
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
D35B12 Sprocket With Stock Bore Features
D35B12 Sprocket With Stock Bore Specifications
This D35B12 sprocket is a durable, high quality, and precision double sprocket with hardened teeth. Sprockets that have hardened teeth last longer and are much more durable than those that don't. Something else that is notable about this sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #35-2 double roller chain and sprocket thus preventing premature wear or breakage. This sprocket is also black oxide coated which increases resistance to the environment and will prevent early rust build up. D35B12 sprockets with a stock bore comes with the standard 1/2" ID hole with no keyway or set screws and can be easily machine bored to custom sizes. If you are needing a custom bore sprocket we have the capabilities on providing those to within a fast lead time and at really great prices.
D35B12 Dimensions:
- Sprocket Size: D35B12
- Outside Diameter: 1.63"
- Hub Type: B
- Stock Bore: 1/2"
- Maximum Recommended Bore: 9/16"
- Hub Diameter: 63/34"
- Length Through Bore: 1-1/4"
- Sprocket Weight: 0.4 LBS
- Sprocket Size: D35B12
- Outside Diameter: 1.630"
- Hub Type: B
- Stock Bore: 1/2"
- Maximum Recommended Bore: 9/16"
- Hub Diameter: 63/64"
- Length Through Bore: 1-1/4"
- Sprocket Weight: 0.32 LBS
