Splined Hub With Flange for 34mm Shaft With 6 Splines - Stainless Material

This top-tier splined hub with a flange is designed for a 34mm shaft with 6 splines, crafted from precision stainless steel that meets ISO DIN 14 standards for straightforward interchangeability. Made from 303-grade stainless steel, this hub is ideal for use in abrasive, corrosive, and food-grade environments. Flanged splined hubs play a crucial role in accurate torque transmission across a wide range of applications. Tailored for a 34mm diameter splined shaft with 6 splines, it allows for easy installation and dependable, long-lasting performance. We also offer splined clamp collars with four pre-drilled holes to complement this hub. For more information or to request a quote on our premium splined hub with flange for a 34mm shaft with 6 splines, please reach out to our customer service team, who will be happy to assist you!

34mm With 6 Splines Hub With Flange Dimensions

• Made for Shaft Diameter: 34mm
• Profile Description: KN28x34
• Material: Stainless
• Part #: 64899509
• Dimension (A): 78mm
• Dimension (B): 60mm
• Dimension (B1): 9.0mm
• Dimension (C): 46mm
• Dimension (F): 45mm
• Dimension (d): 28mm
• Dimension (E): 12mm
• Dimension (h): 3.5mm
• Dimension (L): 60mm
• Weight: 0.64 KG
