Power Transmission > Shafting > Precision Metric Spline Shaft ISO DIN 14 Standards
16mm Spline Shaft 6-Splines C45 Material - 2000mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64845400-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
16mm Spline Shaft 6-Splines C45 Material - 2000mm Features
16mm Spline Shaft 6-Splines C45 Material - 2000mm Specifications
Our high-quality 16mm spline shaft with 6 splines is precision-manufactured from C45 steel and pre-cut to 2000mm for convenience. Following DIN ISO 14 Standards, this 16mm spline shaft is essential for applications that rely on accurate torque transmission and alignment, including drive shafts, agricultural machinery, and industrial equipment. This shaft is built for durability and high performance, and we also offer a range of compatible components such as spline hubs, collars, and clamps. For additional information or a quote on our precision C45 steel 16mm spline shaft with 6 splines in a 2000mm length, contact our customer service team, and we will gladly assist you!
16mm Spline Shaft With 6-Splines Dimensions
- Shaft Diameter (D): 16mm
- Amount of Splines: 6
- Dimension (d): 13mm
- Dimension (b): 3.5mm
- Length: 2000mm
- Material: C45
- Weight: 1.287 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 16mm
- Amount of Splines: 6
- Dimension (d): 13mm
- Dimension (b): 3.5mm
- Length: 2000mm
- Material: C45
- Weight: 1.287 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
