W1SSX Bearing | Stainless Steel V-Guide Wheel Roller Bearing

The size 1 W1SSX v-guide wheel roller bearing is a modern engineering miracle for effective long-term linear motion requirements. V-guide wheel bearings offer the ultimate design flexibility for virtually any guided motion application. Having a 90-degree angle, the v-bearing creates a natural wiping action while also clearing debris from the system. W1SSX bearings are made from high-quality 440C stainless steel and are utilized in corrosive conditions, including; medical, laboratory, food, and beverage. The W1SSX bearing features NBR seals for protection, keeping the internal lubricant in while unwanted debris is out; this bearing is fantastic for any environment with corrosive conditions. For more information or a quote on W1SSX stainless steel bearings and accessories, please get in touch with our customer support team, and we will be happy to assist you!

W1SSX V-Guide Bearing Dimensions

• Part #: W1SSX
• Protection: Shield
• Wheel Material: 440C Stainless Steel
• Ball Retainer Material: Nylon 6,6
• Shield Material: 300 Stainless Steel
• Grease Type: Shell Alvania EP2
• Temperature Range (�F): -22 to +212
• Outside Diameter (D): 0.771"
• Width (W): 0.310"
• Bore Size (B): 0.1875" +0.0000"/ -0.0003"
• Vee Radius Inside (VRI): 0.313"
• Vee Radius Outside (VRO): 0.468"
• Weight (g): 11.1
