By Application > Mining Chain & Sprockets > High-Strength Mining Round Link Chain
14X50 Half Shackle | Round Link Half Shackle
Note:
Custom Cut to Length Chain Also Available
SKU: 14X50-HALF-SHACKLE
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
14X50 Half Shackle | Round Link Half Shackle Features
14X50 Half Shackle | Round Link Half Shackle Specifications
Our 14X50 half shackle is made from high-quality steel to precision tolerances to ensure optimal performance, wear life, and strength. This specific half shackle is particularly made for a 14X50 round link chain and features two bolt holes for hardware. It is important to note that when installing a 14X50 half shackle, dimension C below should not be reduced by more than 0.020". For additional information or to get a quote on our 14X50 half shackles, contact our customer support team, and we will gladly assist you!
14X50 Half Shackle Dimensions
- Chain Size: 14X50
- Bolts: 2
- Dimension (D): 1.19"
- Dimension (C): 3.74"
- Dimension (B): 5.88"
- Dimension (A-Bolt): 0.63"
- Dimension (G): 0.76"
- Dimension (E): 0.50"
- Dimension (F): 0.56"
- Weight: 0.60 LBS
- Chain Size: 14X50
- Bolts: 2
- Dimension (D): 1.19"
- Dimension (C): 3.74"
- Dimension (B): 5.88"
- Dimension (A-Bolt): 0.63"
- Dimension (G): 0.76"
- Dimension (E): 0.50"
- Dimension (F): 0.56"
- Weight: 0.60 LBS
