081B9 Sprocket With Stock Bore

This 081B9 sprocket with a stock bore is a metric roller chain sprocket manufactured under ISO and British Standard 228. Our 081B9 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. Besides the stock bore we also can supply these sprockets with a specific plain or finished (has key-way and set screws) bore size. We also offer upgrades on our 081B9 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 9 tooth sprocket, we also stock a high-quality 081 roller chain and a wide array of roller chain accessories. For more information or to get a quote on 081B9 sprockets, please contact us and one of our sales team members will be happy to assist you.

081B9 Sprocket Dimensions

• Sprocket Size: 081B9
• Tooth Count: 9
• Pitch Diameter (O): 37.13mm
• Outside Diameter (K): 43.4mm
• Hub Diameter (N): 25mm
• Stock Bore (D): 8mm
• Maximum Recommended Bore: 18mm
• Length Thru Bore (L): 14mm
• Sprocket Tooth Width: 3mm
• Sprocket Weight: 0.06 kg
