Pintle Chain Sprockets

Our line of pintle chain sprockets ranges in bore size, hub type (A-plate, B-Hub, or C-Hub), and material (cast or steel). Please note that the majority of our steel sprockets are supplied with heat-treating on the teeth but additional hardened is available upon request. We also supply split, idler, and segmented tooth sprockets. All of our American steel pintle chain sprockets are manufactured using the ASME elongated tooth structure to promote longevity and a self-cleaning design to prevent chain jumping. What separates our pintle chain sprockets from others is the high-quality steel and high-grade cast materials used for each sprocket type, also the majority of our sprockets are manufactured right here in the USA! We also stock a full line of premium quality pintle chains.

Stock Pintle Chain Sprockets include chain sizes: 662, 667H, 667X, 667XH, 667J, 88C, 88K, 88XH
Non-Stock Pintle Chain Sprockets include chain sizes: 308C and 58, these can be manufactured within 1-2 weeks
Note: Our sprockets directly interchange with other sprocket and chain brands.

Pintle Chain Sprocket Size Chart

This chart shows the standard tooth-count size for each pintle chain size. For additional information select the tooth count needed or part number, or contact us.

662	667	667H	667J	667X	667XH	88C	88K	88XH
6-tooth	667B6	667H B6	667J B6	667X B6	667XH B6	88C6	88C6	88C6
7-tooth	667B8	667H B8	667J B8	667X B8	667XH B8	88C7	88C7	88C7
8-tooth	667B9	667H B9	667J B9	667X B9	667XH B9	88C8	88C8	88C8
9-tooth	667C6	667H C6	667J C6	667X C6	667XH C6	88C9	88C9	88C9
10-tooth	667C8	667H C8	667J C8	667X C8	667XH C8	88C10	88C10	88C10
11-tooth	--	--	--	--	--	88C11	88C11	88C11
12-tooth	--	--	--	--	--	88C12	88C12	88C12
13-tooth	--	--	--	--	--	88C14	88C14	88C14
14-tooth	--	--	--	--	--	88C16	88C16	88C16
15-tooth	--	--	--	--	--	88C19	88C19	88C19
16-tooth	--	--	--	--	--	--	--	--
17-tooth	--	--	--	--	--	--	--	--
18-tooth	--	--	--	--	--	--	--	--
19-tooth	--	--	--	--	--	--	--	--
20-tooth	--	--	--	--	--	--	--	--

Additional sizes available upon request.

How to Identify Pintle Chain Sprockets

If you don't know what sprocket you have or need here are step-by-step instructions as to identifying your sprockets.

Step 1:
The very first step is going to be identifying what chain you are currently using. If you already know this then proceed to the next step. If not, go to our How To Identify Pintle Chain Page.

Step 2:
The next step is simply counting your sprocket teeth, this is known as the tooth count.

Step 3:
Next is to identify the hub-type.

Above are the three common hub types (A-plate, B-Hub, and C-Hub).

Step 4:
If your sprocket is a B-Hub or C-Hub we need to measure and identify the bore size and type.

A plane bore is typically a plain hole located in the center of the sprocket and a finished bore is typically furnished with a key-way and two set-screws.

Step 5:
The final step is making note of the material (cast, steel, or other) and designating if the sprocket is a solid construction or a two-piece split sprocket along with any other special or custom modifications that may be done to your specific pintle chain sprocket. With this information contact us and we will quote you.



New! We now also stock Pacific Industries (PII) brand steel pintle chain sprockets!

Requesting Pintle Chain Sprockets

To get a quote on pintle chain sprockets fill out the request for quote form and someone from our customer service team will contact you.
