RLS18 Ball Bearing | RLS18 Bearing - 2-1/4"x4-1/2"x7/8" $0.00 -
RMS16 Ball Bearing | RMS16 Bearing - 2"x4-1/2"x1-1/16" $0.00 -
RLS48 Ball Bearing | RLS48 Bearing - 6"x10-1/2"x1-9/16" $0.00 -
RMS4 Ball Bearing | RMS4 Bearing - 1/2"x1-5/8"x5/8" $0.00 -
RMS15 Ball Bearing | RMS15 Bearing - 1-7/8"x4-1/2"x1-1/16" $0.00 -
RMS12 Ball Bearing | RMS12 Bearing - 1-1/2"x3-3/4"x15/16" $0.00 -
RMS30 Ball Bearing | RMS30 Bearing - 3-3/4"x8-1/4"x1-3/4" $0.00 -
R4-2RS Ball Bearing | R4-2RS Bearing - 1/4"x5/8"x0.196" $9.99 -
RLS24 Ball Bearing | RLS24 Bearing - 3"x5-3/4"x1-1/16" $0.00 -
R6 Ball Bearing | R6 Bearing - 3/8"x7/8"x0.2188" $6.99 -
RLS38 Ball Bearing | RLS38 Bearing - 4-3/4"x8-1/4"x1-5/16" $0.00 -
RLS28 Ball Bearing | RLS28 Bearing - 3-1/2"x6-1/2"x1-1/8" $0.00 -
RMS7 Ball Bearing | RMS7 Bearing - 7/8"x2-1/4"x11/16" $0.00 -
RMS14 Ball Bearing | RMS14 Bearing - 1-3/4"x4-1/4"x1-1/16" $0.00 -
RLS52 Ball Bearing | RLS52 Bearing - 6-1/2"x11"x1-9/16" $0.00 -
R10-2RS Ball Bearing | R10-2RS Bearing - 5/8"x1-3/8"x0.2812" $13.99 -
R16 Ball Bearing | R16 Bearing - 1"x2"x0.375" $12.99 -
RLS12 Ball Bearing | RLS12 Bearing - 1-1/2"x3-1/4"x3/4" $0.00 -
R4A-ZZ Ball Bearing | R4A-ZZ Bearing - 1/4"x3/4"x0.2812" $11.99 -
RLS9 Ball Bearing | RLS9 Bearing - 1-1/8"x2-1/2"x3/8" $0.00 -
RMS22 Ball Bearing | RMS22 Bearing - 2-3/4"x6-1/4"x1-3/8" $0.00 -
RMS36 Ball Bearing | RMS36 Bearing - 4-1/2"x9-3/8"x2" $0.00 -
RMS27 Ball Bearing | RMS27 Bearing - 3-3/8"x7-1/2"x1-9/16" $0.00 -
R3 Ball Bearing | R3 Bearing - 3/16x1/2"x0.1562" $7.99
Deep Groove Ball Bearing Imperial Sizes
Imperial inch size ball bearings are some of the most common deep groove ball bearings used today. Standard inch round bore sizes range from 0.0937" up to 1.375". We supply imperial ball bearings in a slew of configurations; open, sealed on both sides (-2RS), sealed on one side (-RS), shielded on both sides (-ZZ), shielded on one side (-Z), and snap ring (NR). Supplying one of the largest selections of premium ball-bearings USA Roller Chain & Sprockets sets it's self apart from others by being a tier 1 industry-leading ball bearing supplier with an A+ BBB rating. We also stock a range of additional power transmission and industrial components, for more information or to place an order please contact us and we will be happy to assist you.
 Open (No Seal or Sheild) |
 RS (Seal on One Side) |
 2-RS (Seal on Both Sid) |
 Z (Shield on One Sides) |
 ZZ (Shields on Both Sides) |
 NR (Retaining Ring) |
|---|---|---|---|---|---|
R-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width Open (B) | Width Sealed (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Grease Limiting Speed 2RS (RPM) | Grease Limiting Speed ZZ/ Open (RPM) | Oil Limiting Speed Open (RPM) |
|---|---|---|---|---|---|---|---|---|---|
| R2 |
1/8" |
3/8" | 0.1562" | 0.1562" | 140LBS | 49LBS | 26400 | 49000 | 58000 |
| R2A | 1/8" | 1/2" | 0.1719" | 0.1719" | 255LBS | 90LBS | 29200 | 42000 | 51000 |
| R3 | 3/16" | 1/2" | 0.1562" | 0.196" | 292LBS | 109LBS | 24600 | 41000 | 48000 |
| R3A | 3/16" | 5/8" | 0.196" | 0.196" | 292LBS | 109LBS | 24600 | 41000 | 48000 |
| R4 | 1/4" | 5/8" | 0.196" | 0.196" | 360LBS | 150LBS | 21600 | 36000 | 43000 |
| R4A | 1/4" | 3/4" | 0.2188" | 0.2812" | 590LBS | 239LBS | 20400 | 34000 | 40000 |
| R6 | 3/8" | 7/8" | 0.2188" | 0.2812" | 750LBS | 315LBS | 18600 | 31000 | 37000 |
| R8 | 1/2" | 1-1/8" | 0.25" | 0.3125" | 1,150LBS | 540LBS | 15600 | 26000 | 30000 |
| R10 | 5/8" | 1-3/8" | 0.2812" | 0.343" | 1,340LBS | 7288LBS | 12000 | 20000 | 23000 |
| R12 | 3/4" | 1-5/8" | 0.3125" | 0.4375" | 2,110LBS | 1,120LBS | 10800 | 18000 | 21000 |
| R14 | 7/8" | 1-7/8" | 0.375" | 0.5" | 2,270LBS | 1,310LBS | 9000 | 15000 | 18000 |
| R16 | 1" | 2" | 0.375" | 0.5" | 2,270LBS | 1,310LBS | 8400 | 14000 | 16000 |
| R18 | 1-1/8" | 2-1/8" | 0.375" | 0.5" | 2,980LBS | 1,860LBS | 7800 | 13000 | 15000 |
| R20 | 1-1/4" | 2-1/4" | 0.375" | 0.5" | 2,980LBS | 1,860LBS | 7500 | 12000 | 14000 |
| R22 | 1-3/8" | 2-1/2" | 0.4375" | 0.5625" | 3,590LBS | 2,320LBS | 7200 | 11000 | 12500 |
| R24 | 1-1/2" | 2-5/8" | 0.4375" | 0.5625" | 3,770LBS | 2,590LBS | 6900 | 10000 | 11500 |
RLS-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Limiting Speed (RPM) |
|---|---|---|---|---|---|---|
| RLS4 | 1/2" | 1-5/16" | 3/8" | 703LBS | 316LBS | 32,000 |
| RLS5 | 5/8" | 1-9/16" | 7/16" | 976LBS | 459LBS | 24,000 |
| RLS6 | 3/4" | 1-7/8" | 9/16" | 1,296LBS | 633LBS | 20,000 |
| RLS7 | 7/8" | 2" | 9/16" | 1,541LBS | 765LBS | 19,000 |
| RLS8 | 1" | 2-1/4" | 5/8" | 1,816LBS | 898LBS | 17,000 |
| RLS9 | 1-1/8" | 2-1/2" | 5/8" | 1,990LBS | 1,020LBS | 15,000 |
| RLS10 | 1-1/4" | 2-3/4" | 11/16" | 2,296LBS | 1,204LBS | 14,000 |
| RLS11 | 1-3/8" | 3" | 11/16" | 2,602LBS | 1,398LBS | 13,000 |
| RLS12 | 1-1/2" | 3-1/4" | 3/4" | 3,133LBS | 1,694LBS | 11,000 |
| RLS13 | 1-5/8" | 3-1/2" | 3/4" | 3,388LBS | 1,898LBS | 11,000 |
| RLS14 | 1-3/4" | 3-3/4" | 13/16" | 3,582LBS | 2,000LBS | 10,000 |
| RLS16 | 2" | 4" | 13/16" | 4,449LBS | 2,551LBS | 10,000 |
| RLS18 | 2-1/4" | 4-1/2" | 7/8" | 4,847LBS | 2,857LBS | 8,000 |
| RLS20 | 2-1/2" | 5" | 15/16" | 6,306LBS | 3,827LBS | 7,000 |
| RLS22 | 2-3/4" | 5-1/4" | 15/16" | 6,765LBS | 4,133LBS | 6,400 |
| RLS24 | 3" | 5-3/4" | 1-1/16" | 7,163LBS | 4,592LBS | 6,000 |
| RLS26 | 3-1/4" | 6" | 1-1/16" | 8,490LBS | 5,408LBS | 5,800 |
| RLS28 | 3-1/2" | 6-1/2" | 1-1/8" | 9,755LBS | 6,327LBS | 5,300 |
| RLS30 | 3-3/4" | 6-3/4" | 1-1/8" | 11,020LBS | 7,092LBS | 5,000 |
| RLS32 | 4" | 7-1/4" | 1-1/4" | 12,653LBS | 8,163LBS | 4,700 |
| RLS34 | 4-1/4" | 7-1/2" | 1-1/4" | 12,653LBS | 8,316LBS | 4,500 |
| RLS36 | 4-1/2" | 8" | 1-5/16" | 13,265LBS | 8,827LBS | 4,300 |
| RLS38 | 4-3/4" | 8-1/4" | 1-5/16" | 14,082LBS | 9,694LBS | 4,100 |
| RLS40 | 5" | 9" | 1-3/8" | 15,102LBS | 11,020LBS | 3,800 |
| RLS44 | 5-1/2" | 9-1/2" | 1-3/88" | 15,918LBS | 11,837LBS | 3,600 |
| RLS48 | 6" | 10-1/2" | 1-9/16" | 17,755LBS | 13,980LBS | 3,200 |
| RLS52 | 6-1/2" | 11" | 1-9/16" | 18,980LBS | 15,306LBS | 3,000 |
RMS-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Limiting Speed (RPM) |
|---|---|---|---|---|---|---|
| RMS4 | 1/2" | 1-5/8" | 5/8" | 1,163LBS | 510LBS | 23,000 |
| RMS5 | 5/8" | 1-13/16" | 5/8" | 1,378LBS | 668LBS | 22,000 |
| RMS6 | 3/4" | 2" | 11/16" | 1,622LBS | 796LBS | 19,000 |
| RMS7 | 7/8" | 2-1/4" | 11/16" | 1,898LBS | 934LBS | 18,000 |
| RMS8 | 1" | 2-1/2" | 3/4" | 2,296LBS | 1,163LBS | 16,000 |
| RMS9 | 1-1/8" | 2-13/16" | 13/16" | 2,867LBS | 1,490LBS | 13,000 |
| RMS10 | 1-1/4" | 3-1/8" | 7/8" | 3,388LBS | 1,837LBS | 12,000 |
| RMS11 | 1-3/8" | 3-1/2" | 7/8" | 4,184LBS | 2,286LBS | 11,000 |
| RMS12 | 1-1/2" | 3-3/4" | 15/16" | 4,184LBS | 2,286LBS | 11,000 |
| RMS13 | 1-5/8" | 4" | 15/16" | 5,378LBS | 3,061LBS | 9,500 |
| RMS14 | 1-3/4" | 4-1/4" | 1-1/16" | 6,306LBS | 3,673LBS | 8,500 |
| RMS15 | 1-7/8" | 4-1/2" | 1-1/16" | 6,306LBS | 3,622LBS | 6,800 |
| RMS16 | 2" | 4-1/2" | 1-1/16" | 6,306LBS | 3,673LBS | 6,700 |
| RMS18 | 2-1/4" | 5" | 1-1/4" | 8,357LBS | 4,898LBS | 7,000 |
| RMS20 | 2-1/2" | 5-1/2" | 1-1/4" | 9,418LBS | 5,714LBS | 6,700 |
| RMS22 | 2-3/4" | 6-1/4" | 1-3/8" | 10,612LBS | 6,429LBS | 6,300 |
| RMS24 | 3" | 7" | 1-9/16" | 12,653LBS | 8,163LBS | 5,300 |
| RMS26 | 3-1/4" | 7-1/2" | 1-9/16" | 14,592LBS | 10,000LBS | 5,000 |
| RMS27 | 3-3/8" | 7-1/2" | 1-9/16" | 14,592LBS | 10,000LBS | 5,000 |
| RMS28 | 3-1/2" | 8-1/8" | 1-3/4" | 14,592LBS | 11,224LBS | 4,500 |
| RMS30 | 3-3/4" | 8-1/4" | 1-3/4" | 15,612LBS | 11,020LBS | 4,400 |
| RMS32 | 4" | 1-3/4" | 1-3/4" | 17,755LBS | 13,469LBS | 4,300 |
| RMS34 | 4-1/4" | 1-3/4" | 1-3/4" | 17,755LBS | 13,469LBS | 4,000 |
| RMS36 | 4-1/2" | 2" | 2" | 20,714LBS | 16,936LBS | 3,800 |
