RMS9 Ball Bearing | RMS9 Bearing - 1-1/8"x2-13/16"x13/16" $0.00 -
RMS24 Ball Bearing | RMS24 Bearing - 3"x7"x1-9/16" $0.00 -
RMS5 Ball Bearing | RMS5 Bearing - 5/8"x1-13/16"x5/8" $0.00 -
RMS11 Ball Bearing | RMS11 Bearing - 1-3/8"x3-1/2"x7/8" $0.00 -
RMS32 Ball Bearing | RMS32 Bearing - 4"x8-1/2"x1-3/4" $0.00 -
RMS26 Ball Bearing | RMS26 Bearing - 3-1/4"x7-1/2"x1-9/16 $0.00 -
RMS8 Ball Bearing | RMS8 Bearing - 1"x2-1/2"x3/4" $0.00 -
R8-ZZ Ball Bearing | R8-ZZ Bearing - 1/2"x1-1/8"x0.3125" $13.99 -
RMS20 Ball Bearing | RMS20 Bearing - 2-1/2"x5-1/2"x1-1/4" $0.00 -
RLS26 Ball Bearing | RLS26 Bearing - 3-1/4"x6"x1-1/16" $0.00 -
RMS34 Ball Bearing | RMS34 Bearing - 4-1/4"x8-3/4"x1-3/4" $0.00 -
R3A-2RS Ball Bearing | R3A-2RS Bearing - 3/16"x1/2"x0.196" $0.00 -
R2A-2RS Ball Bearing | R2A-2RS Bearing - 1/8"x1/2"x0.1719" $0.00 -
RLS4 Ball Bearing | RLS4 Bearing - 1/2"x1-5/16"x3/8" $0.00 -
R4A Ball Bearing | R4A Bearing - 1/4"x3/4"x0.2188" $6.99 -
RLS22 Ball Bearing | RLS22 Bearing - 2-3/4"x5-1/4"x15/16" $0.00 -
RMS28 Ball Bearing | RMS28 Bearing - 3-1/2"x8-1/8"x1-3/4" $0.00 -
R8-2RS Ball Bearing | R8-2RS Bearing - 1/2"x1-1/8"x0.3125" $13.99 -
RLS20 Ball Bearing | RLS20 Bearing - 2-3/4"x5"x15/16" $0.00 -
R20 Ball Bearing | R20 Bearing - 1-1/4"x2-1/4"x0.375" $18.99 -
R18-2RS Ball Bearing | R18-2RS Bearing - 1-1/8"x2-1/8"x0.5" $21.99 -
RLS7 Ball Bearing | RLS7 Bearing - 7/8"x2"x9/16" $0.00 -
RLS44 Ball Bearing | RLS44 Bearing - 5-1/2"x9-1/2"x1-3/8" $0.00 -
R14 Ball Bearing | R14 Bearing - 7/8"x1-7/8"x0.375" $11.99
Deep Groove Ball Bearing Imperial Sizes
Imperial inch size ball bearings are some of the most common deep groove ball bearings used today. Standard inch round bore sizes range from 0.0937" up to 1.375". We supply imperial ball bearings in a slew of configurations; open, sealed on both sides (-2RS), sealed on one side (-RS), shielded on both sides (-ZZ), shielded on one side (-Z), and snap ring (NR). Supplying one of the largest selections of premium ball-bearings USA Roller Chain & Sprockets sets it's self apart from others by being a tier 1 industry-leading ball bearing supplier with an A+ BBB rating. We also stock a range of additional power transmission and industrial components, for more information or to place an order please contact us and we will be happy to assist you.
 Open (No Seal or Sheild) |
 RS (Seal on One Side) |
 2-RS (Seal on Both Sid) |
 Z (Shield on One Sides) |
 ZZ (Shields on Both Sides) |
 NR (Retaining Ring) |
|---|---|---|---|---|---|
R-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width Open (B) | Width Sealed (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Grease Limiting Speed 2RS (RPM) | Grease Limiting Speed ZZ/ Open (RPM) | Oil Limiting Speed Open (RPM) |
|---|---|---|---|---|---|---|---|---|---|
| R2 |
1/8" |
3/8" | 0.1562" | 0.1562" | 140LBS | 49LBS | 26400 | 49000 | 58000 |
| R2A | 1/8" | 1/2" | 0.1719" | 0.1719" | 255LBS | 90LBS | 29200 | 42000 | 51000 |
| R3 | 3/16" | 1/2" | 0.1562" | 0.196" | 292LBS | 109LBS | 24600 | 41000 | 48000 |
| R3A | 3/16" | 5/8" | 0.196" | 0.196" | 292LBS | 109LBS | 24600 | 41000 | 48000 |
| R4 | 1/4" | 5/8" | 0.196" | 0.196" | 360LBS | 150LBS | 21600 | 36000 | 43000 |
| R4A | 1/4" | 3/4" | 0.2188" | 0.2812" | 590LBS | 239LBS | 20400 | 34000 | 40000 |
| R6 | 3/8" | 7/8" | 0.2188" | 0.2812" | 750LBS | 315LBS | 18600 | 31000 | 37000 |
| R8 | 1/2" | 1-1/8" | 0.25" | 0.3125" | 1,150LBS | 540LBS | 15600 | 26000 | 30000 |
| R10 | 5/8" | 1-3/8" | 0.2812" | 0.343" | 1,340LBS | 7288LBS | 12000 | 20000 | 23000 |
| R12 | 3/4" | 1-5/8" | 0.3125" | 0.4375" | 2,110LBS | 1,120LBS | 10800 | 18000 | 21000 |
| R14 | 7/8" | 1-7/8" | 0.375" | 0.5" | 2,270LBS | 1,310LBS | 9000 | 15000 | 18000 |
| R16 | 1" | 2" | 0.375" | 0.5" | 2,270LBS | 1,310LBS | 8400 | 14000 | 16000 |
| R18 | 1-1/8" | 2-1/8" | 0.375" | 0.5" | 2,980LBS | 1,860LBS | 7800 | 13000 | 15000 |
| R20 | 1-1/4" | 2-1/4" | 0.375" | 0.5" | 2,980LBS | 1,860LBS | 7500 | 12000 | 14000 |
| R22 | 1-3/8" | 2-1/2" | 0.4375" | 0.5625" | 3,590LBS | 2,320LBS | 7200 | 11000 | 12500 |
| R24 | 1-1/2" | 2-5/8" | 0.4375" | 0.5625" | 3,770LBS | 2,590LBS | 6900 | 10000 | 11500 |
RLS-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Limiting Speed (RPM) |
|---|---|---|---|---|---|---|
| RLS4 | 1/2" | 1-5/16" | 3/8" | 703LBS | 316LBS | 32,000 |
| RLS5 | 5/8" | 1-9/16" | 7/16" | 976LBS | 459LBS | 24,000 |
| RLS6 | 3/4" | 1-7/8" | 9/16" | 1,296LBS | 633LBS | 20,000 |
| RLS7 | 7/8" | 2" | 9/16" | 1,541LBS | 765LBS | 19,000 |
| RLS8 | 1" | 2-1/4" | 5/8" | 1,816LBS | 898LBS | 17,000 |
| RLS9 | 1-1/8" | 2-1/2" | 5/8" | 1,990LBS | 1,020LBS | 15,000 |
| RLS10 | 1-1/4" | 2-3/4" | 11/16" | 2,296LBS | 1,204LBS | 14,000 |
| RLS11 | 1-3/8" | 3" | 11/16" | 2,602LBS | 1,398LBS | 13,000 |
| RLS12 | 1-1/2" | 3-1/4" | 3/4" | 3,133LBS | 1,694LBS | 11,000 |
| RLS13 | 1-5/8" | 3-1/2" | 3/4" | 3,388LBS | 1,898LBS | 11,000 |
| RLS14 | 1-3/4" | 3-3/4" | 13/16" | 3,582LBS | 2,000LBS | 10,000 |
| RLS16 | 2" | 4" | 13/16" | 4,449LBS | 2,551LBS | 10,000 |
| RLS18 | 2-1/4" | 4-1/2" | 7/8" | 4,847LBS | 2,857LBS | 8,000 |
| RLS20 | 2-1/2" | 5" | 15/16" | 6,306LBS | 3,827LBS | 7,000 |
| RLS22 | 2-3/4" | 5-1/4" | 15/16" | 6,765LBS | 4,133LBS | 6,400 |
| RLS24 | 3" | 5-3/4" | 1-1/16" | 7,163LBS | 4,592LBS | 6,000 |
| RLS26 | 3-1/4" | 6" | 1-1/16" | 8,490LBS | 5,408LBS | 5,800 |
| RLS28 | 3-1/2" | 6-1/2" | 1-1/8" | 9,755LBS | 6,327LBS | 5,300 |
| RLS30 | 3-3/4" | 6-3/4" | 1-1/8" | 11,020LBS | 7,092LBS | 5,000 |
| RLS32 | 4" | 7-1/4" | 1-1/4" | 12,653LBS | 8,163LBS | 4,700 |
| RLS34 | 4-1/4" | 7-1/2" | 1-1/4" | 12,653LBS | 8,316LBS | 4,500 |
| RLS36 | 4-1/2" | 8" | 1-5/16" | 13,265LBS | 8,827LBS | 4,300 |
| RLS38 | 4-3/4" | 8-1/4" | 1-5/16" | 14,082LBS | 9,694LBS | 4,100 |
| RLS40 | 5" | 9" | 1-3/8" | 15,102LBS | 11,020LBS | 3,800 |
| RLS44 | 5-1/2" | 9-1/2" | 1-3/88" | 15,918LBS | 11,837LBS | 3,600 |
| RLS48 | 6" | 10-1/2" | 1-9/16" | 17,755LBS | 13,980LBS | 3,200 |
| RLS52 | 6-1/2" | 11" | 1-9/16" | 18,980LBS | 15,306LBS | 3,000 |
RMS-Series Inch Ball Bearings
| Bearing Size | Bore (d) | Diameter (D) | Width (B) | Dynamic Load Rating (LBS) | Static Load Rating (LBS) | Limiting Speed (RPM) |
|---|---|---|---|---|---|---|
| RMS4 | 1/2" | 1-5/8" | 5/8" | 1,163LBS | 510LBS | 23,000 |
| RMS5 | 5/8" | 1-13/16" | 5/8" | 1,378LBS | 668LBS | 22,000 |
| RMS6 | 3/4" | 2" | 11/16" | 1,622LBS | 796LBS | 19,000 |
| RMS7 | 7/8" | 2-1/4" | 11/16" | 1,898LBS | 934LBS | 18,000 |
| RMS8 | 1" | 2-1/2" | 3/4" | 2,296LBS | 1,163LBS | 16,000 |
| RMS9 | 1-1/8" | 2-13/16" | 13/16" | 2,867LBS | 1,490LBS | 13,000 |
| RMS10 | 1-1/4" | 3-1/8" | 7/8" | 3,388LBS | 1,837LBS | 12,000 |
| RMS11 | 1-3/8" | 3-1/2" | 7/8" | 4,184LBS | 2,286LBS | 11,000 |
| RMS12 | 1-1/2" | 3-3/4" | 15/16" | 4,184LBS | 2,286LBS | 11,000 |
| RMS13 | 1-5/8" | 4" | 15/16" | 5,378LBS | 3,061LBS | 9,500 |
| RMS14 | 1-3/4" | 4-1/4" | 1-1/16" | 6,306LBS | 3,673LBS | 8,500 |
| RMS15 | 1-7/8" | 4-1/2" | 1-1/16" | 6,306LBS | 3,622LBS | 6,800 |
| RMS16 | 2" | 4-1/2" | 1-1/16" | 6,306LBS | 3,673LBS | 6,700 |
| RMS18 | 2-1/4" | 5" | 1-1/4" | 8,357LBS | 4,898LBS | 7,000 |
| RMS20 | 2-1/2" | 5-1/2" | 1-1/4" | 9,418LBS | 5,714LBS | 6,700 |
| RMS22 | 2-3/4" | 6-1/4" | 1-3/8" | 10,612LBS | 6,429LBS | 6,300 |
| RMS24 | 3" | 7" | 1-9/16" | 12,653LBS | 8,163LBS | 5,300 |
| RMS26 | 3-1/4" | 7-1/2" | 1-9/16" | 14,592LBS | 10,000LBS | 5,000 |
| RMS27 | 3-3/8" | 7-1/2" | 1-9/16" | 14,592LBS | 10,000LBS | 5,000 |
| RMS28 | 3-1/2" | 8-1/8" | 1-3/4" | 14,592LBS | 11,224LBS | 4,500 |
| RMS30 | 3-3/4" | 8-1/4" | 1-3/4" | 15,612LBS | 11,020LBS | 4,400 |
| RMS32 | 4" | 1-3/4" | 1-3/4" | 17,755LBS | 13,469LBS | 4,300 |
| RMS34 | 4-1/4" | 1-3/4" | 1-3/4" | 17,755LBS | 13,469LBS | 4,000 |
| RMS36 | 4-1/2" | 2" | 2" | 20,714LBS | 16,936LBS | 3,800 |
