C55B Camelback Chain

C55B Camelback Chain

Note: Custom Cut to Length Chain Also Available
Product Code: C55B-CAMELBACK-CHAIN
View full details
Description
Specification
C55B camelback chain is categorized as a cast combination chain. This C55B camelback chain is a high quality, durable, and long lasting conveyor chain that is manufactured using high quality components. C55B camelback chain is used in a wide range of applications including; bucket elevators, flight conveyors, forest products, grain handling, sugar processing, and more! C55B camelback chain links are manufactured to be symmetrical which means that this chain can travel in either direction. This C55B camelback chain has the capability of conveying both abrasive and non-abrasive materials which greatly broadens its range of applications that it can be used in. This chain is supplied as riveted construction furnished with pin heads all on the same side. We also offer a full line of C55B camelback chain sprockets and other accessories. For pricing and availability please contact us and we will be happy to assist you.

Dimensions:

  • Chain Type: C55B Camelback Chain
  • Pitch: 1.631"
  • Pin Diameter (D): 0.375"
  • Sidebar Thickness (T): 0.190"
  • Barrel Diameter (Q): 0.720"
  • Maximum Allowable Sprocket Face (S): 0.690"
  • Overall Height (P): 1.250"
  • Overall Width Riveted (A): 2.000"
  • Head Of Pin To Center Line (C): 1.000"
  • Overall Length Of Barrel (X): 1.250"
  • Sidebar Height (H): 0.750"
  • Height Of Shoulder (F): 0.750"
  • Center Of Pin To Top (J): 0.880"
  • Style Of Top: Peaked
  • Links Per 10ft: 74
  • Weight Per Foot: 3.2 LBS
  • Ultimate Strength: 117,000 LBS
  • Maximum Working Load: 1,400 LBS

Phone: (407) 347-3519
Email: sales@usarollerchain.com

Feature

  • C55B Camelback Chain
  • High Quality C55B Camelback Chain
  • Extremely Durable
  • C55B Sprockets Available
  • Able To Travel In Both Directions
Featured image
  • Chain Type: C55B Camelback Chain
  • Pitch: 1.631"
  • Pin Diameter (D): 0.375"
  • Sidebar Thickness (T): 0.190"
  • Barrel Diameter (Q): 0.720"
  • Maximum Allowable Sprocket Face (S): 0.690"
  • Overall Height (P): 1.250"
  • Overall Width Riveted (A): 2.000"
  • Head Of Pin To Center Line (C): 1.000"
  • Overall Length Of Barrel (X): 1.250"
  • Sidebar Height (H): 0.750"
  • Height Of Shoulder (F): 0.750"
  • Center Of Pin To Top (J): 0.880"
  • Style Of Top: Peaked
  • Links Per 10ft: 74
  • Weight Per Foot: 3.2 LBS
  • Ultimate Strength: 117,000 LBS
  • Maximum Working Load: 1,400 LBS
