C2040 Roller Chain - 10ft Box

C2040 Roller Chain is Also Commonly Known As C2040 Double Pitch Roller Chain and C2040 Conveyor Chain. This C2040 Roller Chain fully meets all ANSI Standards and is a durable and dependable product. Economy Plus C2040 double pitch roller chain has a tensile strength of 3,500lbs and is supplied in 10ft boxes including one connecting link, but alternate lengths are available per request. We also offer additional connecting links and offset links, along with a full line of C2040 sprockets and attachments. For more information about C2040 roller chain or to get a quote on sprockets, or attachments give us a call!

C2040 Roller Chain Dimensions

• Pitch (P): 1.000"
• Roller Width (W): 0.312"
• Roller Diameter (R): 0.312"
• Plate Height (H): 0.463"
• Plate Thickness (T): 0.060"
• Pin Diameter (D): 0.156"
• Overall Width (F): 0.640"
• Tensile Strength: 3,500lbs
• Weight: 0.34 lbs/ft

Important Note:
When looking for C2040 roller chain (photo below on the left) it is important to not mix it up with C2042 roller chain (photo below on the right). This is a common and easy mistake to make because both of these chains are manufactured with the same side-plates, meaning that the part number stamped on the side of both chains is most likely "C2040".
VS.

C2040 Roller Chain Sprockets

Besides the roller chain we also stock a complete line of premium quality double pitch sprockets. These sprockets are manufactured out of SAE-1045 steel, have hardened teeth, and are black oxide coated. The chart below shows stock sizes of double pitch sprockets as well as their dimensions. This is helpful for identifying current sprockets or for designing a new application. If you don't see the exact sprockets you need please contact us and we will be happy to assist you.

Stock C2040 Roller Chain Sprockets

Sprocket Size	Tooth Count	Outside Diameter	Stock Bore	Maximum Bore	Length Thru Bore	Weight
2040B11	11	2.00"	1/2"	13/16"	7/8"	0.34 LBS
2040B12	12	2.17"	1/2"	13/16"	7/8"	0.44 LBS
2040B13	13	2.33"	1/2"	21/32"	7/8"	0.48 LBS
2040B14	14	2.49"	1/2"	1-1/32"	7/8"	0.60 LBS
2040B15	15	2.65"	5/8"	1-7/32"	7/8"	0.66 LBS
2040B16	16	2.81"	5/8"	1-9/32"	7/8"	0.76 LBS
2040B17	17	2.98"	5/8"	1-5/16"	1"	1.00 LBS
2040B18	18	3.14"	5/8"	1-15/32"	1"	1.16 LBS
2040B19	19	3.30"	5/8"	1-5/8"	1"	1.36 LBS
2040B20	20	3.46"	5/8"	1-3/4"	1"	1.54 LBS
2040B21	21	3.62"	5/8"	1-25/32"	1"	1.74 LBS
2040B22	22	3.78"	5/8"	1-7/8"	1"	1.92 LBS
2040B23	23	3.94"	5/8"	2"	1"	2.16 LBS
2040B24	24	4.10"	5/8"	2-1/4"	1"	2.44 LBS
2040B25	25	4.26"	5/8"	2-1/4"	1"	2.48 LBS
2040B26	26	4.42"	5/8"	2-1/4"	1"	2.60 LBS
2040B28	28	4.74"	5/8"	2-1/4"	1"	2.74 LBS
2040B30	30	5.06"	5/8"	2-1/4"	1"	2.92 LBS
