WHX5121 Chain (Drag Chain)

Specialty Chain > Engineering Class Chains > More Engineer Class Chains > Cast and Steel Fabricated Drag Chains > 5121 Chain

WHX5121 Chain (Drag Chain)

Note: Custom Cut to Length Chain Also Available
SKU: WHX5121-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock Item is unavailable

Login to Request a Quote

<p>Don’t see what you need?</p>

Don’t see what you need?

Call us

Buy it With:

 [{"variant_id":"51715504505199" , "metafield_value":""}]
WHX5121 Chain (Drag Chain) Features
WHX5121 Chain (Drag Chain) Specifications
WHX5121 chain is a heavy-duty steel fabricated steel drag chain that features a 27,600 LB working load. This chain is made to handle the most abrasive applications by having hardened surfaces, square edges, and induction hardened pins. Heat treating the surfaces makes the chain have a much higher wear life, while induction hardened pins provide the benefits of a thru-hardened pin while having a higher resistance to abrasion. This WHX5121 chain is engineered and manufactured to provide the maximum strength and the longest wear life. We also offer a full line of high quality WHX5121 sprockets. For more information or to get a quote please contact us and we will be happy to assist you.

WHX5121 Chain Dimensions

WHX5121 Chain (Drag Chain)
  • Chain Size: WHX5121
  • Pitch: 9.00"
  • Overall Width (A): 9.873"
  • Inside Width (L): 3.630"
  • Pin Diameter (G): 1.250"
  • Barrel Diameter (D): 2.50"
  • Sidebar Height (H): 2.50"
  • Sidebar Thickness (T): 1.125"
  • Flight Width: 10" - 30"
  • Breaking Load: 275,000 LBS
  • Rated Working Load: 27,600 LBS
  • Chain Size: WHX5121
  • Pitch: 9.00"
  • Overall Width (A): 9.873"
  • Inside Width (L): 3.630"
  • Pin Diameter (G): 1.250"
  • Barrel Diameter (D): 2.50"
  • Sidebar Height (H): 2.50"
  • Sidebar Thickness (T): 1.125"
  • Flight Width: 10" - 30"
  • Rated Working Load: 27,600 LBS
