S52 Roller Chain - Agricultural Chain
S52 Roller Chain - Agricultural Chain
Note:
Custom Cut to Length Chain Also Available
Product Code: S52-CHAIN
Shipping calculated at checkout.
Couldn't load pickup availability
S52 chain is manufactured to DIN8189 standards and is primary used in agricultural equipment. This S52 roller chain features solid rollers, heat treated components, and is supplied with a light high-quality lubricant for extended working life. For additional chain lubricant checkout our roller chain lubricant page! Besides S52 roller chain we also offer sprockets, attachments, bearings, shafting, motors, reducers and much more. For additional information or to get pricing please contact our customer support team and we will be happy to assist you.
S52 Chain Dimensions
- Pitch (P): 38.10mm
- Roller Diameter (d1): 15.24mm
- Width Between Inner Plates (b1): 22.23mm
- Pin Diameter (d2): 5.72mm
- Pin Length (L): 37.7mm
- Connecting Link Pin Length (Lc): 40.4mm
- Inner Plate Depth (h2): 17.3mm
- Plate Thickness (T): 2.8mm
- Tensile Strength: 7,868 LBS
- Weight Per Meter: 3.70 LBS
Feature
- High Quality Agricultural Chain
- Manufactured in Accordance to DIN 8189 Standards
- Extremely Durable and High Performance
- Pitch (P): 38.10mm
- Roller Diameter (d1): 15.24mm
- Width Between Inner Plates (b1): 22.23mm
- Pin Diameter (d2): 5.72mm
- Pin Length (L): 37.7mm
- Connecting Link Pin Length (Lc): 40.4mm
- Inner Plate Depth (h2): 17.3mm
- Plate Thickness (T): 2.8mm
- Tensile Strength: 7,868 LBS
- Weight Per Meter: 3.70 LBS
