Premium Metric 10B-2 Roller Chain - 10ft Box
Note:
Custom Cut to Length Chain Also Available
$279.99
SKU: P-10B-2-ROLLER-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
Premium Metric 10B-2 Roller Chain - 10ft Box Features
Premium Metric 10B-2 Roller Chain - 10ft Box Specifications
The premium duplex 10B-2 roller chain is a 15.875mm pitch metric roller chain that dimensionally conforms to ISO and British (BS) standards. What sets our 10B-2 chain apart is top-grade steel alloys, precision components, heat-treated & shot-peened components, factory preloading, and exceptionally hardened pins. Our tier-one 10B-2 roller chain provides extended service life and excellent performance and can operate within the most demanding 10B-2 applications! We also offer 10B-2 chain sprockets, guides, chain breakers, pullers, and spare links. For additional information or a quote, contact our customer service team; we will gladly assist you!
10B-2 Roller Chain Dimensions
- Part #: 10B-2
- Pitch (P): 15.875mm
- Roller Width (R): 9.65mm
- Roller Diameter (D): 10.16mm
- Overall Width (W): 35.65mm
- Connecting Link Overall Width (X): 40.30mm
- Plate Height (H): 14.70mm
- Plate Thickness (T): 1.70mm
- Pin Diameter (L): 5.08mm
- Minimum Breaking Load: 4,580 KGS
- Weight: 1.8 kG/ m
- Part #: 10B-2
- Pitch (P): 15.875mm
- Roller Width (R): 9.65mm
- Roller Diameter (D): 10.16mm
- Overall Width (W): 35.65mm
- Connecting Link Overall Width (X): 40.30mm
- Plate Height (H): 14.70mm
- Plate Thickness (T): 1.70mm
- Pin Diameter (L): 5.08mm
- Minimum Breaking Load: 4,580 KGS
- Weight: 1.8 kG/ m
