General Duty Plus #35 Nickel Plated Chain - 10ft Box
$44.99
SKU: G35-NICKEL-PLATED-CHAIN
In stockOnly 0 left in stockBackordered
Out of stock
Item is unavailable
Contact Us For Pricing & Availability
Carbon Steel Chains
| Features | Premium/Premier | General Duty Plus | Economy Plus |
|---|---|---|---|
| Solid Bushings | Split Bushings in most cases | Split Bushings | |
| Solid Rollers | |||
| Through-Hardened Pins | Case-Hardened Pins | Heat-Treated Pins | |
| Case-Hardened Rollers | Heat-Treated in Some Chains | ||
| Case-Hardened Bushings | Heat-Treated in Some Chains | ||
| Wide Contour Plates | Standard Contour Plates | Standard Contour Plates | |
| Superior Pin to Plate Contact | |||
| High-Hold Riveting | Standard Dual-Stake Rivets | Standard Dual-Stake Rivets | |
| Factory Pre-Loading | Not Standard on Economy Chains | ||
| Specific Heat-Treatment on Every Component | Some Components Might be Heat-Treated | ||
| Premium Alloy & Carbon Materials | High-Quality Carbon Materials | Standard-Quality Carbon Materials | |
| Shot-Peened Components | Non Shot-Peened Components | Non Shot-Peened Components | |
| High-Precision Components | Standard Precision Components | Low Precision Components | |
| Conforms to ANSI B29.1 or ISO/DIN Standards |
General Duty Plus #35 Nickel Plated Chain - 10ft Box Description/Features
General Duty Plus #35 Nickel Plated Chain - 10ft Box Specifications
This #35 nickel plated chain is a durable, high quality, and high strength roller chain that fully meets all ANSI Standards. Nickel plated roller chain is good in humid or slightly corrosive environments where normal roller chain tends to rust easily. The General Duty Plus #35 nickel plated roller chain features heat treated parts that have been nickel plated evenly and fully which eliminates stress cracking, unwanted wear, and easy corrosion attack. Some of the advantages of the General Duty Plus Series nickel plated roller chain over the Economy Plus Series chain is that it uses a higher quality carbon steel, a better nickel plating, and features fully heat treated components. Doing these things to a roller chain drastically increases the strength, durability, working life, and overall performance of the chain. Additionally, this chain is just as strong as the standard General Duty Plus carbon steel roller chain and will work on the same sprockets. #35 nickel plated roller chain is commonly supplied in 10ft boxes including one connecting link in each box. However we can supply this chain on larger length reels and even custom lengths to meet your applications exact needs. We also offer nickel plated attachments and a full line of high quality ANSI #35 sprockets.
#35 Nickel Plated Chain Dimensions
- Part Number: #35NP
- Tensile Strength: 2,400 LBS
- Pitch (P): 0.375"
- Roller Width (W): 0.188"
- Roller Diameter (D): 0.200"
- Chain Overall Width (F): 0.460"
- Overall Width Of Connecting Link: 0.500"
- Link Plate Height (H): 0.356"
- Link Plate Thickness (T): 0.050"
- Pin Diameter (E): 0.141"
- Weight Per Foot: 0.22 LBS
- Part Number: #35NP
- Tensile Strength: 2,400 LBS
- Pitch (P): 0.375"
- Roller Width (W): 0.188"
- Roller Diameter (D): 0.200"
- Chain Overall Width (F): 0.460"
- Overall Width Of Connecting Link: 0.500"
- Link Plate Height (H): 0.356"
- Link Plate Thickness (T): 0.050"
- Pin Diameter (E): 0.141"
- Weight Per Foot: 0.22 LBS
