200 Roller Chain | 200 Chain - ANSI Roller Chain

200 roller chain is one of the largest ANSI roller chains on the market! Ringing in with a pitch of 2.500" and average tensile strength of 99,924 LBS, this series of 200 roller chains are made to work. Here at USA Roller Chain, we supply three different quality levels of 200 chain, ranging from Economy Plus (this one), General Duty Plus, and Premier Series/ Premium. Having three different quality levels of 200 roller chain to choose from, our clients can best select their chain for their application. With that being said, our Economy Series 200 chain still outperforms he competition within this price range, showcasing features such as solid rollers, heat-treated and shot-peened components, and factory pre-loading to minimize stretch. In addition, we aimed to supply a quality roller chain within a budgetary price range. Besides the 200 chain itself, we also stock 200 chain sprockets and chain tools for making maintaining your roller chain easier! Our 200 roller chains are supplied as a 10ft box, including one connecting (master) link to ensure you have everything you need to hook up your brand-new chain. Contact our customer service team for additional information on our products, and we will be happy to assist you!

200 Roller Chain Dimensions

• ANSI Chain Size: 200
• Tensile Strength: 99,924 LBS
• Pitch (P): 2.500"
• Roller Diameter (D1): 1.562"
• Width Between Inner Plates (B1): 1.500"
• Pin Diameter (D2): 0.781"
• Chain Pin Length (LR): 3.16"
• Connecting Link Pin Length (LC): 3.56"
• Inner Plate Height (H2): 2.36"
• Plate Thickness (T): 0.312"
• Chain Weight: 11.4 LBS/ FT
