Power-Link #40 Roller Chain - 10ft Box
#40 roller chain is a 1/2" pitch ANSI B29.1 industrial duty roller chain that is manufactured with precision components and high-strength carbon steel alloys. Being made to ANSI dimensional standards means that this chain directly interlaces with other brands and interlaces. What we do above and beyond that standard is heat-treat the individual chain components, utilize precision machined parts, and shot peen chain parts for increased fatigue resistance and overall durability. With a high-tensile strength of 3,700 LBS this chain possess an excellent side-to-strength ratio, as well as weight-to-strength ratio (Chain weighs 0.41 LBS/ FT). #40 roller chain is one of the most common chain sizes used around the world today because of its versatility and productive nature. We stock this chain in 10ft boxes with a connecting link but additional packaging options are available from stock!
#40 Roller Chain Dimensions
| Size | Pitch (P) | Roller Width (W) | Roller Diameter (D) | Overall Width (A) | Plate Height (H) | Plate Thickness (T) | Pin Diameter (E) | Weight (Per Ft) |
|---|---|---|---|---|---|---|---|---|
| 40-1 | 0.50" | 0.312" | 0.312" | 0.650" | 0.472" | 0.059" | 0.156" | 0.42 Lbs. |
Note: overall width of cottered-style #40 roller chains will vary.
