Specialty Chain > ANSI Leaf Chains
BL2022 Leaf Chain
Note:
Custom Cut to Length Chain Also Available
SKU: BL2022-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
Buy it With:
BL2022 Leaf Chain Features
BL2022 Leaf Chain Specifications
BL2022 Leaf Chain is manufactured to ANSI (American) standards and is a heavy-duty series of leaf chain. The most common applications for leaf chain is forklifts, material handling, and lifting applications that require a high strength and heavy duty chain. The standard BL2022 leaf chain that we offer is manufactured using high quality components (pins and plates) that have gone through special manufacturing processes to ensure strength and durability, more so than other leaf chains on the market. This chain has a 2X2 lacing and is supplied as 10ft boxes, reels (25ft - 100ft), and cut to length sections upon request.
Standard Series Specifications:
USA Roller Chain and Sprockets is easy to work with and we offer an extensive inventory, high quality products at competitive prices, and fast response times. We sell to end users, distributors, as well as OEMs all around the world. For more information or to get pricing and availability on BL2022 Leaf Chain please contact us and we will be happy to assist you.
Phone: (407) 347-3519
Email: sales@usarollerchain.com
Click Here To See Our Other Products!
- Chain Size: BL2022
- Pitch (P): 2.500"
- Pin Diameter (A): 0.938"
- Plate thickness (B): 0.391"
- Plate Height (C): 2.376"
- Pin Length (D): 2.040"
- Chain Weight: 10.62 LBS/ Ft
- Tensile Strength: 102,000 LBS
BL2022 leaf chain may see limited usage compared to other BL series chains, but it remains a viable option for demanding hoisting, lifting, and material handling needs. Its load-bearing capacity allows utilization with port material handling equipment such as forklifts, chassis flippers, top handlers, straddle carriers, empty container handlers, top lifts, and log stackers.
Email:
Click Here To See Our Other Products!
- Chain Size: BL2022
- Pitch (P): 2.500"
- Pin Diameter (A): 0.938"
- Plate thickness (B): 0.391"
- Plate Height (C): 2.376"
- Pin Length (D): 2.040"
- Chain Weight: 10.62 LBS/ Ft
- Tensile Strength: 102,000 LBS
