90 Volt 1/3 HP DC Electric Motor | 1800RPM - TENV, C-Face, 56C Frame, Removable Base

This 90 volt Direct Current (DC) 1/3 hp electric motor is designed for applications that need simple variable speed controlled motor. Specifically this motor is rated for 1800 RPM, is totally enclosed non-ventilated (TENV) for dusty and outdoor applications and can easily be used with an alternating current (AC) source with the use of a DC controller. The 1/3 horsepower DC motor utilizes a durable construction, IP54 rating of protection, and uses the common C-face 56C frame for drop-in replacing other brands. The motors base is removable and it has an industry leading 1.0 service factor. Utilizing a high-quality electric motor is essential for reducing downtime and increasing overall productivity. Besides the motor we can also supply the required reducer along with any other products needed such as; roller chain, roller chain sprockets, v-belts, v-belt pulleys, DC controller, and many more. For more information or to get a quote please contact us and we will be happy to assist you.

1/3 HP DC Electric Motor Features

• 1800 RPM
• 90 Volt
• TENV Enclosure (IP54 protection)
• 1.0 Service Factor
• Class F Insulation
• C-Face/ Removable Base
• 20:1 Speed Range at Constant Torque
• High Starting Torque

Non-Reversing Variable Speed Drive WDCCONT-90	Reversing Variable Speed Drive WDCCONTREV-90

WPMDC13-18-90V-56CB Electric Motor Dimensions
