WDH102 Chain Description/Features
WDH102 Chain Specifications
WDH102 chain features a large and wide pushing area, which gives it the capability of caring a sizable capacity when operating at low to even moderate speeds. WDH102 welded steel chain is found in a wide range of applications including; conveyors, forest products, grain handling, heavy duty conveyors, pulp and paper industry, sugar processing, and more! This WDH102 drag chain is engineered to be durable, reliable, and high strength. Then manufactured using a select grade of high quality heat-treated alloy steels to provide a long working life with solid performance. Additionally, this chain features heat-treated components including the pins, barrels, and side plates. Doing this makes the chain drastically stronger and makes it have a much longer working life.

WDH-102 Chain Dimensions

WDH102 Chain
  • Chain Size: WDH102
  • Pitch (A): 5.00"
  • Ultimate Strength: 61,000 LBS
  • Sidebar Height (B): 1-1/2"
  • Sidebar Thickness (C): 3/8"
  • Pin Diameter (D): 3/4"
  • Overall Width (E): 9-1/4"
  • Length Of Bearing (F): 7-3/4"
  • Maximum Sprocket Thickness (G): 6-3/8"
  • Links Per Foot: 2.4
  • Weight Per Foot: 12 LBS


We offer a full line of high quality WDH102 chain sprockets that exceed in quality, working life, and are supplied at remarkably great prices. We can even supply custom made to order sprockets within a really great lead-time.

WDH102 Chain


We can also supply WDH102 wing attachments along with the C 1/2 - C4 attachments and have them assembled onto the chain in any configuration needed.

WDH102 Chain


For pricing and availability on WDH102 chain, sprockets, or attachments please contact us.
