18" Screw Conveyor Discharge Spout With Hand Slide | 342-2664
Note:
Custom Cut to Length Chain Also Available
SKU: 7222-342-2664
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
18" Screw Conveyor Discharge Spout With Hand Slide | 342-2664 Features
18" Screw Conveyor Discharge Spout With Hand Slide | 342-2664 Specifications
The 342-2664 18" screw conveyor discharge spout with a hand slide is fitted to the conveyor trough or trough openings, it's made from high-strength 12-gauge steel. The slide can be operated parallel to the trough or at right angles. We also supply spouts made to specific dimensions and configurations upon request, they can also be furnished out of special materials required by the application. For additional information or to get a quote on a 18" screw conveyor discharge spout with a hand slide contact our customer support team and we will be happy to assist you!
18" Discharge Spout With Hand Slide Dimensions
- Part #: 342-2664
- Diameter of Conveyor: 18"
- Gauge of Steel: 64
- Weight: 30 LBS
- Dimension (A): 19"
- Dimension (B): 14-1/2"
- Dimension (C): 12-3/8"
- Dimension (G-H): 24-1/4"
- Dimension (J): 33-3/4"
- Dimension (K): 1-1/8"
- Dimension (L): 4-7/16"
- Dimension (M): 4-3/8"
- Dimension (N): 4-3/8"
- Dimension (P): 1/2"
- Size of Bolt (R): 2-3/4"
- Part #: 342-2664
- Diameter of Conveyor: 18"
- Gauge of Steel: 64
- Weight: 30 LBS
- Dimension (A): 19"
- Dimension (B): 14-1/2"
- Dimension (C): 12-3/8"
- Dimension (G-H): 24-1/4"
- Dimension (J): 33-3/4"
- Dimension (K): 1-1/8"
- Dimension (L): 4-7/16"
- Dimension (M): 4-3/8"
- Dimension (N): 4-3/8"
- Dimension (P): 1/2"
- Size of Bolt (R): 2-3/4"
