54mm Spline Shaft 8-Splines 304SS Material - 2000mm
54mm Spline Shaft 8-Splines 304SS Material - 2000mm
Note:
Custom Cut to Length Chain Also Available
Product Code: 64899464-SHAFT
Shipping calculated at checkout.
Couldn't load pickup availability
Other Customers Viewed
Our premium stainless 54mm spline shaft, featuring 8 splines and measuring 2000mm in length, is precisely machined from 304-grade stainless steel, ensuring superior resistance to corrosion and abrasion. Ideal for food-grade, high-temperature, and low-temperature environments, this shaft adheres to DIN ISO 14 standards, guaranteeing compatibility and interchangeability with other brands and components such as hubs, collars, and couplings. While available in a 2000mm length, we also offer other standard or custom lengths of stainless 54mm splined shafting. Designed for precise and efficient torque transmission, it is perfect for industrial machinery, food processing equipment, and mechanical drives. Additionally, stainless 54mm spline shafts can be used for mechanically positioning components. For more information or to request a quote on our premium stainless 54mm spline shaft with 8 splines in a 2000mm length, please contact our customer service team, and we will be happy to assist you!
54mm Spline Shaft With 8-Splines Dimensions
- Shaft Diameter (D): 54mm
- Amount of Splines: 8
- Dimension (d): 46mm
- Dimension (b): 9mm
- Length: 2000mm
- Material: 304SS
- Weight: 15.30 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
Feature
- High Precision 54mm Splined Shaft
- Features 8-Splines
- Made From 304 Stainless Steel Material
- Cut to a 2000mm Length
- Conforms to ISO DIN 14 Dimensions
- Resistant to Corrosion & Abrasion
- Shaft Diameter (D): 54mm
- Amount of Splines: 8
- Dimension (d): 46mm
- Dimension (b): 9mm
- Length: 2000mm
- Material: 304SS
- Weight: 15.30 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
