60B8 Sprocket With Stock Bore

Name: 60B8 Sprocket With Stock Bore
Brand: USA ROLLER CHAIN
SKU: 60B8-SPROCKET
Price: 18.99 USD
Availability: InStock

$18.99

SKU: 60B8-SPROCKET

In stockOnly 0 left in stockBackordered Out of stock Item is unavailable

Request a Quote

Don’t see what you need? In a rush?

Call us!

Buy it With:

60B8 Sprocket With Stock Bore Description/Features

60B8 Sprocket With Stock Bore Specifications

This 60B8 sprocket is a durable, high quality, and precision sprocket with 8 hardened teeth. Sprockets that have hardened teeth last longer and are much more durable than those that don't. Something else that is notable about this 60B8 sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #60 roller chain and sprocket thus preventing premature wear or breakage. This sprocket is also fully black oxide coated which increases resistance to the environment and will prevent early rust build up. 60B8H sprockets with a stock bore comes with the standard 5/8" ID hole with no keyway or set screws and can be easily machine bored to custom sizes. We also offer sprockets with finished bore configurations right off the shelf from stock, and if you are needing a custom bore sprocket we the capabilities on providing those to within a fast lead time and at really great prices. Fore more information or to get a formal quote please contact us and we will be happy to assist you.

Dimensions:

Sprocket Size: 60B8
Tooth Count: 8
Hub Type: B
Outside Diameter: 2.260"
Stock Bore Size: 5/8"
Maximum Bore Size: 5/8"
Hub Diameter: 1-15/32"
Length Thru Bore: 1-1/4"
Weight: 0.54 LBS
Common Interchanges: 60B8H, H60B8, 60B8-SB
