35B8 Sprocket With Stock Bore ANSI Sprocket

Home > Power Transmission > Sprockets > Roller Chain Sprockets > 8-Tooth Sprocket for #35 Chain with Stock Bore, 35B8

8-Tooth Sprocket for #35 Chain with Stock Bore, 35B8

Name: 8-Tooth Sprocket for #35 Chain with Stock Bore, 35B8
Brand: USA ROLLER CHAIN
SKU: 35B8-SPROCKET
Price: 4.99 USD
Availability: InStock

Note: Contact Us For Large Quantity Request

$4.99

SKU: 35B8-SPROCKET

In stockOnly 0 left in stockBackordered Out of stock Item is unavailable

Request a Quote

Don’t see what you need? In a rush?

Call us!

Buy it With:

8-Tooth Sprocket for #35 Chain with Stock Bore, 35B8 Description/Features

8-Tooth Sprocket for #35 Chain with Stock Bore, 35B8 Specifications

This 35B8 sprocket is a durable, high quality, and precision sprocket with hardened teeth. Sprockets that have hardened teeth last longer and are much more durable than those that don't. Something else that is notable about this sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #35 roller chain and sprocket which prevents premature wear or breakage. This sprocket is also black oxide coated which increases resistance to the environment and will prevent early rust build up. 35B8 sprockets with a stock bore comes with the standard 3/8" ID hole with no keyway or set screws and can be easily machine bored to custom sizes. We also offer sprockets with finished bore configurations right off the shelf from stock, and if you are needing a custom bore sprocket we the capabilities on providing those to within a fast lead time and at really great prices.

35B8 Sprocket Dimension

Sprocket Size: 35B8
Tooth Count: 8
Hub Style: B
Outside Diameter (O.D): 1.130"
Stock Bore: 3/8"
Recommended Maximum Bore: 3/8"
Hub Diameter: 3/4"
Length Thru Bore: 3/4"
Sprocket Weight: 0.07 LBS
Common Interchanges: 35B8H, H35B8, 35B8-SB
