W4XLSSX Bearing | Stainless Steel V-Guide Wheel Roller Bearing

The size 4XL W4XLSSX v-guide wheel roller bearing is a modern engineering miracle for effective long-term linear motion requirements. V-guide wheel bearings offer the ultimate design flexibility for virtually any guided motion application. Having a 90-degree angle, the v-bearing creates a natural wiping action while also clearing debris from the system. W4XLSSX bearings are made from high-quality 440C stainless steel and are utilized in corrosive conditions, including; medical, laboratory, food, and beverage. The W4XLSSX bearing features special stainless steel and NBR shield/ seals for protection, keeping the internal lubricant in while unwanted debris is out; this bearing is fantastic for any environment with corrosive conditions. For more information or a quote on W4XLSSX stainless steel bearings and accessories, please get in touch with our customer support team, and we will be happy to assist you!

W4XLSSX V-Guide Bearing Dimensions

• Part #: W4XLSSX
• Protection: Seal/ Shield
• Wheel Material: 440C Stainless Steel
• Ball Retainer Material: Nylon 6,6
• Shield Material: 300 Stainless Steel
• Seal Material: NBR
• Grease Type: Shell Alvania EP2
• Temperature Range (�F): -22 to +212
• Outside Diameter (D): 2.968"
• Width (W): 1.000"
• Bore Size (B): 0.8331" +0.0000/ - 0.0004"
• Vee Radius Inside (VRI): 1.250"
• Vee Radius Outside (VRO): 1.750"
• Weight (g): 575.0
