UER205 Insert Bearing | 25mm Insert Bearing With Snap Ring

UER205 bearing is a normal-duty ball bearing insert with a snap ring made to C3 precision standards and utilizes a Tru-Loc devise to secure to a 25mm shaft. Our UER205 insert bearing has several features: a wide inner-ring, steel retainer, anti-rotation device, and an inner ring and outer ring made from bearing grade steel to produce a high-quality and long-lasting bearing. Our UER205 bearing is made to industry standards dimensionally for direct interchangeability with just about any brand. For additional information or to receive a quote on our UER205 bearings, contact our customer service and, we will be happy to assist you!

UER205 Bearing Dimensions

• Part #: UER 205
• Shaft Diameter (d): 25mm
• Setscrew Used: M4 x 0.7
• Dimension (D): 52.0mm
• Dimension (Bi): 35.4mm
• Dimension (Be): 19.0mm
• Dimension (N): 13.1mm
• Dimension (M): 21.8mm
• Dimension (W): 49.0mm
• Dimension (K): 9.5mm
• Dimension (A): 1.1mm
• Dimension (AN): 2.4mm
• Dimension (Y): 57.9mm
• Dimension (T): 5.5mm
• Dynamic Load Rating (kN): 14.04
• Static Load Rating (kN): 8.05
• Weight (kg): 0.2
