UCWFC201-8 bearing is a 1/2" bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 1/2" shaft and has an metric based housing. UCWFC201-8 flange cartridge bearings are designed for circumstances where the bearing is mounted to a surface that is perpendicular to the shaft axis. Our superior UCWFC201-8 bearing with a 1/2" bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCWFC201-8 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set screws. UCWFC201-8 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCWFC201-8 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCWFC201-8 bearings, and we will be happy to assist you!

UCWFC201-8 Bearing Dimensions

• Part #: UCWFC201-8
• Shaft Diameter (d): 1/2"
• Dimension (A): 3.54"
• Dimension (P): 2.76"
• Dimension (E): 1.95"
• Dimension (I): 0.39"
• Dimension (S): 0.39"
• Dimension (J): 0.16"
• Dimension (K): 0.20"
• Dimension (G): 0.75"
• Dimension (F): 2.17"
• Dimension (Z): 1.02"
• Dimension (Bi): 1.0787"
• Dimension (N): 0.3937"
• Dimension (M): 0.6260"
• Bolt Used: 5/16
• Dynamic Load Rating (LBS): 2,147
• Static Load Rating (LBS): 1,075
• Bearing Insert: UCW 201-8
• Housing Number: WFC 203
• Weight (LBS): 1.3
