UCWFC202 Bearing | 15mm 4-Bolt Flange Bearing

UCWFC202 bearing is a 15mm bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 15mm shaft and has an metric based housing. UCWFC202 flange cartridge bearings are designed for circumstances where the bearing is mounted to a surface that is perpendicular to the shaft axis. Our superior UCWFC202 bearing with a 15mm bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCWFC202 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set screws. UCWFC202 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCWFC202 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCWFC202 bearings, and we will be happy to assist you!

UCWFC202 Bearing Dimensions

• Part #: UCWFC202
• Shaft Diameter (d): 15mm
• Dimension (A): 90.0mm
• Dimension (P): 70.0mm
• Dimension (E): 49.5mm
• Dimension (I): 10.0mm
• Dimension (S): 10.0mm
• Dimension (J): 4.0mm
• Dimension (K): 5.0mm
• Dimension (G): 19.0mm
• Dimension (F): 55.0mm
• Dimension (Z): 25.9mm
• Dimension (Bi): 27.4mm
• Dimension (N): 10.0mm
• Dimension (M): 15.9mm
• Bolt Used: M8
• Dynamic Load Rating (kN): 9.55
• Static Load Rating (kN): 4.78
• Bearing Insert: UCW 202
• Housing Number: WFC 203
• Weight (kg): 0.6
