PM720S F226 Attachment

Product Code: PM720S-F226-ATTACHMENT

Get a Quote
Call to Order 407-347-3519

Description

Technical Specs

PM720S F226 Attachment is a plastic material attachment made for PM720S collector chain. The PM720S F226 attachment is made for 6" flights (also known as sludge flights), a 6" filler block, and is commonly accompanied with carry and return wear shoe parts. We can supply the PM720S plastic chain with F226 attachments in any configuration needed, along with the accompanying wear components and hardware. To get a quote on PM720S F226 Attachment links or PM720S chain with F226 attachments please contact us and we will be happy to assist you.

Helpful/ Recommended Tool:

We recommend that you purchase a wastewater chain tool when using plastic 700-series chains. This tool ensures proper installation of the chain and easy disassembly when it is time to replace the chain.

PM720S F226 Dimensions

Chain Size: PM720S
Attachment Type: F226
Material: PM
Pitch: 6.00"
Overall Width: 3.438"
Dimension (A): 3.75"
Dimension (B): 2.625"
Dimension (C): 2.375"
Dimension (D): 0.375"
Dimension (E): 6.125"
Dimension (F): 5.50"
Dimension (G): 3.00"
Dimension (T): 0.313"
Ultimate Tensile Strength: 6,000 LBS
Rated Working Load: 2,600 LBS
Weight: 1.34 LBS
