240B10 Sprocket With Stock Bore

This 240B10 sprocket is high quality, fully meets all ANSI standards, and is supplied as a plain stock bore B-Hub (hub on one side) style sprocket. #240B10 sprockets have 10 teeth, and are supplied with a 1.5" stock bore. However, we can machine bore sprockets out to almost any bore size needed. We offer some of the best prices and customer service in the industry, for pricing and availability please contact us and we will get you exactly what you need at a great price!

240B10 Sprocket Dimensions

• Part Number: #240B10
• Outside Diameter: 11.03"
• Hub Type: B-Hub
• Bore Size: 1-1/2"
• Maximum Bore Size: 4-1/2"
• Hub Diameter: 6-1/2"
• Length Through Bore: 3-3/8"
• Number Of Teeth: 10
• Sprocket Weight: 49lbs
