160F15 Sprocket (QD Type)

160F15 Sprocket

Our Price: $374.99

Note: Se Habla Espanol

Availability: In-Stock
Product Code: 160F15-SPROCKET

Qty:

Description

Technical Specs

This 160F15 sprocket is a durable, high quality, and precision sprocket with 15 hardened teeth that is manufactured to accept a F bushing. Sprockets that have hardened teeth last longer, perform better, and are much more durable than those that don't. Something else that is notable about this sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #160 roller chain and sprocket. Meeting strict ANSI Standards prevents premature wear or breakage as well as making it directly interchangeable with other brands. This sprocket is also black oxide coated which increases resistance to the environment and will prevent early corrosion. 160F15 sprockets are manufactured to accept a F type QD bushing which, we also stock with a wide range of bore sizes. Additionally we offer sprockets with finished bore configurations, and if you need a custom sprocket we have the capabilities on providing them within a fast lead-time and at really great prices. For more information or large quantity request please contact us and we will be happy to assist you.

160F15 Sprocket Dimensions

Sprocket Size: 160F15
Bushing Type: F
Tooth Count: 15
Outside Diameter: 10.610"
Pitch Diameter: 9.620"
Sprocket Type: B1
Maximum Bore: 3-15/16"
Dimension (L1): 3-5/8 "
Dimension (L2): 4"
Dimension (C): 6-5/8"
Dimension (Y): 2-5/16"
Dimension (P): 1/8"
Dimension (G): 1-11/32"
Dimension (X): 2-1/2"
Dimension (T): 1.156"
Bushing Weight: 11.5 LBS
Sprocket Weight: 24.0 LBS
